5 SPECIFICATIONS
POWER CONSUMPTION
CIO-DAC16
+5V supply 435 mA typical, 525 mA max
+12V supply 140 mA typical, 180 mA max
−12V supply 80 mA typical, 105 mA max
CIO-DAC08
+5V supply 435 mA typical, 525 mA max
+12V supply 75 mA typical, 98 mA max
−12V supply 52 mA typical, 68 mA max
ANALOG OUTPUT
D/A type AD7237
Resolution 12 bits
Number of channels
CIO-DAC16 16 Voltage Outputs
CIO-DAC08 8 Voltage Outputs
Output Ranges ±10V, ±5V, ±2.5V, 0 to 10V, 0 to 5V,
0 to 2.5V. Each channel independently
switch-selectable.
D/A pacing Software paced
Data transfer Software
Offset error Adjustable to zero
Gain error Adjustable to zero
Differential non-linearity ±½ LSB max
Integral non-linearity ±½ LSB max
Monotonicity 12 bits
Gain drift (DAC) ±30 ppm/°C max
Offset drift (DAC) ±3 ppm/°C max
Throughput System-dependent
Slew Rate 0.3 V/µs Typical
Settling time (20V step to .01%) 70 µs
Current Drive ±5 mA min
Output short-circuit duration Indefinite
Output coupling DC
Output resistance (OP-07) 0.1 ohm max
Miscellaneous Double-buffered output latches
12
