Advanced operations
RQT5741
º U6: Optimizing the video to suit the material
Icon Content
Transfer MODE
Selects the method of conversion for
progressive output to suit the type of material
being played (➡ page 41, “Film and video”).
Auto 1 (normal): for viewing film material
Auto 2: for viewing film material (the same as
Auto 1, but able to convert 30-frame
per second progressive video)
Auto 3: for animated material (also able to
convert 30-frame per second
progressive video)
Video: for video material
4:3 ASPECT
Selects how to show video on a widescreen
(16:9) television that is compatible with
progressive output.
Nor. (normal): The picture fills the whole
screen.
Auto: Letterbox format 4:3 aspect video
expands to fill the screen or is shown
in the center of the screen with black
bands either side.
Shr. (shrink): The picture is shown in the 4:3
aspect in the center of the
television.
Zoom: Select if video with an aspect of 4:3
recorded in the letterbox format is not
expanded when “Nor.” or “Auto” is
selected.
Shift Position (0 to i15)
Shifts the picture to show subtitles.
(Works when the picture fills the screen when
4:3 ASPECT is set to “Auto” or “Zoom”.)
Crosshatch
ON: Outputs a test pattern to check a
projector’s picture.
OFF
Auto1
Nor.
OFF
0
Icon Content
Color Balance R-Gain (j31 to 0)
Reduces the amount of red in the picture.
Color Balance G-Gain (j31 to 0)
Reduces the amount of green in the picture.
Color Balance B-Gain (j31 to 0)
Reduces the amount of blue in the picture.
Icon Content
Color Balance R-Offset (j15 to i15)
Adds or reduces red.
Color Balance G-Offset (j15 to i15)
Adds or reduces green.
Color Balance B-Offset (j15 to i15)
Adds or reduces blue.
º U5: Adjusting the amount of red, green, and blue in
white
º U4: Adjusting red, green, and blue balance
0
0
0
0
0
PC
PC
PC
PC
PC
PC
0
