48
Appendix
Specifications
Television System NTSC standard
Channel Coverage VHF: 2 through 13
UHF: 14 through 69
Cable TV: Mid band (A-8 through A-1, A through I)
Super band (J through W)
Hyper band (AA through ZZ, AAA, BBB)
Ultra band (65 through 94, 100 through 125)
Power Source 120 V AC, 60 Hz
Power Consumption 32AFX62: 142 W; 36AFX62: 136 W
Audio Power Main : 10 W + 10 W
Sub-woofer : 13 W
Speaker Type Main : Two 2-3/8 × 4-3/4 inches (60 × 120 mm)
Sub-woofer : One 4 inches (100 mm) round
Video/Audio Terminals S-VIDEO INPUT
Y: 1 V(p-p), 75 ohm, negative sync.
C: 0.286 V(p-p) (burst signal), 75 ohm
VIDEO/AUDIO INPUT
VIDEO: 1 V(p-p), 75 ohm, negative sync.
AUDIO: 150 mV(rms) (30% modulation equivalent, 47 kohm)
ColorStream™ (component video) INPUT
Y: 1V(p-p), 75 ohm
C
B: 0.7 V(p-p), 75 ohm
C
R: 0.7 V(p-p), 75 ohm
AUDIO: 150 mV(rms), 47 kohm
VIDEO/AUDIO OUTPUT
VIDEO: 1 V(p-p), 75 ohm, negative sync.
AUDIO: 150 mV(rms) (30% modulation equivalent, 4.7 kohm)
VARIABLE AUDIO OUTPUT
0–300 mV(rms) (30% modulation equivalent, 4.7 kohm)
AUDIO CENTER CHANNEL INPUT
300 mV(rms) (30% modulation equivalent, 10 kohm)
Dimensions 32AFX62 Width : 34-1/2 inches (875 mm)
Height : 26-1/2 inches (673 mm)
Depth : 22-5/8 inches (575 mm)
36AFX62 Width : 38-3/16 inches (970 mm)
Height : 29-9/16 inches (750.9 mm)
Depth : 24-1/4 inches (615 mm)
Mass 32AFX62: 156 lbs. (70.8 kg)
36AFX62: 206 lbs. (93.4 kg)
Supplied Accessories Remote Control with 2 size “AA” alkaline batteries
Optional TV stand 32AFX62: ST3262
36AFX62: ST3662
Design and specifications are subject to change without notice.
