16
Reference sheet of computer input signals
Set output signals in the computer according to the table below after connecting the computer to the TV set properly.
Definition Horizontal frequency (kHz) Vertical frequency (Hz)
640 x 480 31.469 59.940
800 x 600 37.879 60.317
1024 x 768 48.363 60.004
1360 x 768 47.720 59.799
1280 X 1024 63.981 60.000
1920 X 1080 66.587 59.934
Reference sheet of computer HDMI input signals
1. When using the DVI port: Connect the DVI port of the AV equipment to the back of the TV set panel via the DVI-
To-HDMI cable and set the output signal of the AV equipment according to the table below.
2. When using the computer HDMI port: Connect the computer HDMI port to the back of the TV set panel via the
HDMI cable and set the output signal of the computer according to the table below.
Definition
Horizontal frequency (kHz) Vertical frequency (Hz)
640 x 480 31.469 59.940
800 x 600 37.879 60.317
1024 x 768 48.363 60.004
1360 x 768 47.720 59.799
1280 X 1024 63.981 60.000
1920 X 1080 66.587 59.934
Reference sheet of audio input signals
1. Connect the YPbPr port or the HDMI port of the AV equipment to the back of the TV set and set the output signal
of the AV equipment according to the table below.
2. If the computer display adapter may support AV format signals, output signals indicated in the following table may
be set.
Definition
Horizontal frequency (kHz) Vertical frequency (Hz)
720 x 480i 15.734 60
720 x 480p 31.500 60
720 x 576i 15.625 50
720 x 576p 31.250 50
1280 x 720p 37.500 50
1280 x 720p 45.000 60
1920 x 1080i 28.125 50
1920 x 1080i 33.750 60
1920 x 1080p 56.300 50
1920 x 1080p 67.500 60
