3-2
User Guide for Cisco LCD Professional Series Displays
OL-17986-01
Chapter 3 Connecting to Other Devices
Connecting to an Audio Amplifier
Related Topics
• About Terminals on the Back of Your Display, page 2-4
• Connecting to a Digital A/V Source (HDMI), page 3-2
• Connecting to a Digital A/V Source (DVI to HDMI), page 3-3
Connecting to an Audio Amplifier
Procedure
Step 1 Connect a set of audio cables from the left and right AUX jacks on the audio system to the AUDIO OUT
[L-AUDIO-R] terminal of your LCD display.
Related Topics
• About Terminals on the Back of Your Display, page 2-4
• Connecting to an Analog Audio Source, page 3-1
• Connecting to a Digital A/V Source (HDMI), page 3-2
• Connecting to a Digital A/V Source (DVI to HDMI), page 3-3
Connecting to a Digital A/V Source (HDMI)
Procedure
Step 1 Use an HDMI cable to connect the digital input device to the HDMI terminal of your display.
Related Topics
• About Terminals on the Back of Your Display, page 2-4
• Connecting to a Digital A/V Source (DVI to HDMI), page 3-3
• Connecting to an Analog Audio Source, page 3-1
