Product Information
10
Remote Control
!
=
q
w
@
#
$
%
&
+
‘
Q
W
E
^
*
R
e
)
(
r
T
t
Y
I
y
6
1
2
9
0
3
4
U
8
5
7
u
“
! STANDBY/ON button
@ DVD SELECT button
# VCR SELECT button
$
[DVD]
AUDIO LANGUAGE Select,
[VCR]
AUDIO Select button,
[RADIO]
Set FM Mode to Stereo or Mono sound
%
[DVD]
SUBTITLE Select button
^
[DVD]
ZOOM button
&
[VCR]
Channel Up/Down button,
[RADIO]
Tune to the presetted
stations
*
[VCR]
TIMER RECORDING button,
[DVD]
PROGRAM button
( SETUP button
)
[DVD, VCR]
Use to highlight selections on a menu and adjust
certain settings
[RADIO, DVD, VCR]
Adjust the volume
1
[DVD]
TITLE /PBC button
2
[DVD, VCR]
NUMBER button ,
[VCR]
TRACKING –/+ button
3
[DVD]
MARK button
4
[DVD]
REPEAT Playback button
5
[DVD]
REPEAT a defined period from A to B button
6 TV/VCR Select button
7
[DVD, VCR]
CLOCK/COUNTER button
8
[DVD, VCR]
FORWARD / REVERSE SEARCH button,
[RADIO]
Scan all
available radio stations
9
[VCR]
Record button
0
[DVD]
PREVIOUS (move into a previous chapter or track) / NEXT
(Move into a next chapter or track) button,
[RADIO]
RDS/PTY
button
“ SOUND MUTE button
‘
[DVD]
OPEN/CLOSE button,
[VCR]
EJECT button
+
[RADIO]
FM/AM Select button
= VCR INPUT button
Q
[DVD]
Chapter/Title/Time SEARCH button
q SLEEP button
W CLEAR button
w VOLUME CONTROL buttons
E SOUND FIELD button
e
[DVD,VCR]
OSD DISPLAY button
R ENTER (Confirm selections on a menu screen) button
r
[DVD]
MENU button
T SYSTEM select button (This button is not available for this set)
t Sound LEVEL button
Y DELAY button
y
[DVD]
Slow Forward/ Reverse button,
[VCR]
Slow speed button,
[DVD,VCR]
Frame advance (step) in still mode
U PLAY/PAUSE button
u STOP/MEMORY button
I
[DVD]
ANGLE,
[VCR]
Record SPEED button
Press the power [ ] button of the remote control
for about 8 seconds. No buttons of front panel can
be operated now and Lock indicator (“ ”)
will be displayed on window display. To release
child lock, press any button of the remote control.
Child Lock!!!
Instructions in using remote control
• Operate remote control within 7m from the unit.
• Do not press two buttons at the same time.
• Do not light up sending part of remote control.
• Do not keep in the place with much dust and humidity.
Accessories
Remote Control 2 Batteries RF cable
AM antenna
FM antenna
Owner’s Manual/
Warranty
Remote Control
• To purchase accessories or parts not supplied, contact your nearest dealer or service center. But, owner’s
manual and warranty are not sold additionally.
6 Speaker Cables:
• 1 X green/black wire for center speaker
•
1 X red/black wire for front right speaker
•
1 X white/black wire for front left speaker
• 1 X purple/black wire for subwoofer
• 1 X blue/black wire for rear left speaker
•
1 X gray/black wire for rear right speaker
Unpacking The Speakers
• one set of speakers including 1 set of left and right front
speakers, 1 centre speaker, 1 subwoofer and 1 set of left and
right rear speakers.
Front Speakers
Subwoofer
Center Speaker
Rear Speakers
(Surround Sound)
