Protocol X DCA
Configuration Guide
A197-0CG-1.00-2 Restricted
10
Full
Name Range Description
Diagnostics
Interval
-1 (disabled)
0 .. 1000000000
This parameter defines the frequency (in milliseconds) at which the Diagnostic
sequence will be executed. This sequence is used to retrieve the Diagnostic
Counter information and to read the Buffer Overflow Flag from the SRU.
A typical scan interval is 3600000 milliseconds (1 hour).
AI with time No
Yes
This parameter is used to indicate if the analog input information is expected
to be received with or without time when the SRU is polled or when it sends
an unsolicited message.
☞
☞☞
☞NOTE: This parameter should match the way the device is configured
to report analog input information, otherwise the message
could be interpreted incorrectly and the DCA could report
inaccurate analog input information.
First Partition Index into A197_PAR
or
Not Used (-1)
This parameter specifies the first partition definition record that is associated
with this SRU. This offset must be less than the total number of records
defined in the A197_PAR table. The range of partitions specified by this
offset and the Number of Partitions must specify a valid range of A197_PAR
records.
No. of Partitions 0…255 This parameter specifies the number of records in the A197_PAR table that are
associated with this SRU. This value in combination with First Partition
parameter specifies the range of A197_PAR records that define the data
partitions for this port.
The default value is 0.
First System
Parameter
Index into A197_SYS
or
Not Used (-1)
This parameter specifies the first System Parameter definition record that is
associated with this SRU. This offset must be less than the total number of
records defined in the A197_SYS table. The range of partitions specified by
this offset and the Number of Parameters must specify a valid range of
A197_SYS records.
No. Of
Parameters
0…255 This parameter specifies the number of records in the A197_SYS table that are
associated with this SRU. This value in combination with First System
Parameter specifies the range of A197_SYS records that define the System
Parameters for this port.
The default value is 0.
