GE Energy Services
Protocol X DCA
Configuration Guide
A197-0CG-1.00-2 Restricted
14
Full
Address System Parameter Unit Value Default
3000 DI Event Enable 1 = Enable / 0 = Disable 0
3001 DI Change Enable 1 = Enable / 0 = Disable 0
3002 Store To EEPROM Command 1 = Store Parameters
3003 DI Change With Timestamp 1 = Enable / 0 = Disable 0
3004 AI Event With Timestamp 1 = Enable / 0 = Disable 0
3005 Duplex Mode 0 = Half-duplex mode 0
3006 Station Address 8 .. 63, 72 .. 254 101
3007 Scan Alper Cycle 0 = no scan, range 0 .. 1 0
3008 Default AI Delta lowword 0 .. 65535 0x00
3009 Default AI Delta highword 0 .. 32768 0x16
Automatic tuning
3010 Automatic tuning 1 = start / 0 = stop 0
3011 Already tuned signals % Read only 0
3012 Min Events Per Period 1
3013 Max Events Per Period 10
3014 Tuning Period Ms 10
3015 Basic DI Cycle Ms 3 .. 20 5
Automatic tuning
3020 Field 0: Start Address Word Addr. Allen-Bradley Address 100
3021 Field 0: Length Words 0
3022 Field 0: Periode 100ms 0
3023 Field 1: Start Address Word Addr. Allen-Bradley Address 100
3024 Field 1: Length Words 0
3033 Field 2: Length Words 0
3034 Field 2: Periode 100ms 0
Satellite Clock
3055 Channel Parameters 100
Analogue Fields
3070 Field 0: Start Address Word Addr. Allen-Bradley Address 100
3071 Field 0: Length Words AI Lenght
3072 Field 0: Scan Rate X DI Cycle 0
3073 Field 1: Start Address Word Addr. Allen-Bradley Address 100
3074 Field 1: Length Words 0
3083 Field 2: Length Words 0
3084 Field 2: Scan Rate X DI Cycle 0
Table 10 Coupler for Allen-Bradley Data Highway System Parameters.
