GE Energy Services
Protocol X DCA
Configuration Guide
A197-0CG-1.00-2 Restricted
16
Full
Field Range Description
Termination
Character
Disabled
USE ESCAPE SEQUENCE
^A (1)
^B (2)
^C (3)
.
.
.
^Z (26)
If ‘Disabled’ is chosen, the virtual connection will terminate only if a VC
Channel Timeout occurs or if the telnet connection is dropped.
If ‘USE ESCAPE SEQUENCE’ is selected, the user should describe an
escape sequence in the ‘Describe Escape Sequence’ sub-table.
If a termination character is selected (^A, ^B, etc.), this indicates the
character that should be detected for the virtual connection to close.
Note: ‘^’ means to press the CTRL key and, while holding it, press
the key for the specified letter.
Values in parentheses represent the ASCII value of the control
characters.
The default value is ^C (3).
Describe Escape
Sequence
40 Characters A string that will be displayed in the WESMAINT screen explaining to
the user how to enter the escape sequence.
Esc Seq 0..FF (Hex value) Virtual Terminal Escape Sequence. A table with 16 hexadecimal entry
values that describe the escape sequence. The hexadecimal ASCII value
of each character of the desired escape sequence should be entered on
each field. The unused fields should be set to zero.
If any value other than ‘USE ESCAPE SEQUENCE’ is selected in the
Termination Character field, this table will be ignored.
Pre/Post Esc. Seq.
Timer
1..300 Time (in seconds) that must elapse before the escape sequence can be
accepted, and the time that must elapse after the correct escape sequence
is received, without any characters being received so that it is accepted.
The default value is 2 seconds.
VT Connection
Timeout
0 .. 65535 Time (in seconds) that must elapse, with no activity, for the virtual
connection to time out. If a timeout occurs, the virtual channel is
automatically closed. This feature is disabled if the field is set to zero.
The default value is 0 (timeout disabled).
Table 11 Virtual Connection Configuration Table Parameters
