AV32L5/P10EKEI / LCT0909-001A-U / English
DIGITAL SURROUND (Only AV32P10EK
DIGITAL SURROUND (Only AV32P10EKDIGITAL SURROUND (Only AV32P10EK
DIGITAL SURROUND (Only AV32P10EK
and AV32P10EI)
and AV32P10EI)and AV32P10EI)
and AV32P10EI)
You can enjoy the surround sound with any of the five
surround functions.
1
Press the
a
button to display MENU
(main menu)
2
Press the
6
buttons to choose DIGITAL
SURROUND. Then press the OK button
The DIGITAL SURROUND menu is not displayed while
the headphones are connected to the TV. Disconnect
the headphones from the TV.
3
Press the
6
buttons to choose the
function you want to use
To cancel a surround function:
Press the
6
buttons to choose SURROUND OFF.
4
Press the
a
button to complete the setting
The menu disappears.
• When you connect the headphones, all surround
functions will be cancelled.
■
■■
■
3D-PHONIC
3D-PHONIC3D-PHONIC
3D-PHONIC
Dolby Surround Pro Logic surround sound and Dolby Digital
surround sound can be easily enjoyed without additional
surround speakers.
Using rear surround signals of Dolby Surround encoded
programmes or Dolby Digital programmes, this function will
create the surround sound as if surround speakers were
located to your right and left.
When viewing a programme from the EXT
terminal which has been set to DIGITAL-IN:
You can enjoy the atmosphere of the surround sound of
Dolby Digital programmes.
If the programme source has 5.1-channel Dolby Digital
soundtracks, you can enjoy the atmosphere of the
5.1-channel Dolby Digital surround.
When viewing Dolby Surround encoded programmes, you
can enjoy the atmosphere of Dolby Surround Pro Logic
surround sound.
When viewing a programme from the EXT
terminal which has not been set to DIGITAL-IN,
or when viewing a TV broadcasting programme:
When viewing Dolby Surround encoded programmes, you
can enjoy the atmosphere of Dolby Surround Pro Logic
surround sound.
• You can turn this function on or off with a single press. For
details, see “4 3D Button (Only AV32P10EK and
AV32P10EI)” on page 12.
•
For details of how to adjust the surround effect level, adjust
the volume balance of the speakers, and perform the
setting necessary when adding a front speaker system or
subwoofer system, see “3D-PHONIC setting” on page 24.
• This function does not work properly except for Dolby
Surround encoded programmes and Dolby Digital
programmes.
■
■■
■
DOLBY DIGITAL
DOLBY DIGITALDOLBY DIGITAL
DOLBY DIGITAL
You can enjoy the surround sound of Dolby* Digital
programmes and Dolby Surround encoded programmes.
When viewing a programme from the EXT
terminal which has been set to DIGITAL-IN:
You can enjoy the surround sound of Dolby Digital
programmes.
If the programme source has 5.1-channel Dolby Digital
soundtracks, you can enjoy the 5.1-channel Dolby Digital
surround sound.
When viewing the Dolby Surround encoded programmes, you
can enjoy the Dolby Surround Pro Logic surround sound.
When viewing a programme from the EXT
terminal which has not been set to DIGITAL-IN,
or when viewing a TV broadcasting programme:
When viewing the Dolby Surround encoded programmes, you
can enjoy the Dolby Surround Pro Logic surround sound.
• Additional surround speakers are necessary in order to
use this function to enjoy surround sound. Although you
can listen to Dolby Digital audio without surround
speakers, you cannot enjoy surround sound such as
5.1-channel Dolby Digital surround sound.
• Before using this function, correctly set each of the items
in the DOLBY DIGITAL menu in accordance with “DOLBY
DIGITAL setting” on page 24.
• Dolby Digital soundtracks can provide anything from
mono to full 5.1-channel Dolby Digital surround sound.
When a Dolby Digital audio signal is received, the
number of front channels and rear channels included in
the signal are displayed on the screen for a few seconds
as “DOLBY D (number of front channels) / (number of
rear channels)”. If LFE (low frequency effects) are
included in the signal, “ .1” is displayed after the number
of rear channels. For example, “DOLBY D 3/2.1” is
displayed when a 5.1-channel Dolby Digital signal is
received.
• This function does not work properly except for Dolby
Surround encoded programmes and Dolby Digital
programmes.
* Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic”, and the double-D symbol are
trademarks of Dolby Laboratories.
Confidential unpublished works. ©1992-1997 Dolby
Laboratories. All rights reserved.
• Dolby Digital is an advanced form of digital audio coding.
Dolby Digital audio is available from programme sources
(such as DVD-video discs) which are usually identified
with a Dolby Digital logo.
• When you connect the subwoofer system to the TV, you
can enjoy the powerful low frequency effects (LFE) of
5.1-channel Dolby Digital more effectively.
• This TV does not work with digital audio signals other than
Dolby Digital audio. If no sound is emitted from the
speakers, cancel the DIGITAL-IN setting and change to
normal analog sounds.
D0045-EK
3D-PHONIC
DOLBY DIGITAL
DANCE CLUB
CONCERT HALL
STADIUM
SURROUND OFF
BACK
DIGITAL SURROUND
TV OK
MORE
