Note: You can also use a moving background,
but you should make sure that it does not have
a confusing effect in combination with moving
lm reference images. Confusing effects can
sometimes be avoided by making the animated
background menu darker or fuzzier.
Now create a scene of 20 seconds duration
containing video material corresponding in
content to the video material of the rst project
you inserted with the program “DVD-Arabesk
2”. Insert this video scene into the storyboard
behind the xed image.
Go to the transition effects menu and select PIP-
Studio. Insert it between the scenes previously
positioned and set the effect duration also to 20
seconds. Start the program.
You now see your background image and in
front of it your video scene as PIP.
In order to complete the example, make the
following settings for the displayed scene in the
foreground:
Under “PIP” select “Single” and under “Effect”
set “Hard Cut” for “IN” and “OUT”.
Now select as “Shape” a “Rectangle” and set
the “Size” 120 x 96 (for NTSC 120 x 80) in order
to obtain an average-sized picture.
Note: In order to obtain a small reference
picture, select 80 x 64 (NTSC = 80 x 50), for a
large picture use 160 x 128 (NTSC = 160 x 100).
Now go to the menu “Border” and set both
“Size” and “Blur” to 0. Also, the value of
“Distance” in the menu “Shadow” should be
set to 0.
After you have made these settings you can
position the PIP. Click on “Position” and move
the picture, for example, to the upper right
corner to the position 512, 220.
Calculate the PIP-Studio effect and then create a
scene from it that you put in the storyboard.
Insert into the storyboard an additional
video scene with a length of 20 seconds that
corresponds in content to the second project
you inserted with the program “DVD-Arabesk
2”.
Create again a PIP with the same settings (only
the position must be different, of course),
calculate it and create a new scene from it.
When you are nished with the above, you will
have created with PIP-Studio the same number
