NTRODUCTION
AA
AA
Supplied Accessories5
Attaching the Stand
You must attach the stand to the unit to have it as a table top unit. Be sure the front and rear of the stand match the proper
direction.
5
Note:
• When attaching the stand, ensure that all screws are tightly fastened. If the stand is not properly attached, it could cause the unit to fall,
resulting in injuries as well as damage to the unit.
• Make sure to use a table which can support the weight of this unit and is larger than this unit.
• Make sure the table is in a stable location.
1
Spread a thick and soft cloth over a
table as shown below.
Place the main unit face down onto it.
Make sure not to damage the screen.
At least two people are required at
this step.
2
Insert the neck under the bottom
of the main unit to the stand’s hole
(shown by arrow
➀
).
3
Drive Phillips pan screws in the 4
threaded holes at the bottom of the
stand until they are tight.
To remove the stand from this unit
Unscrew the Phillips pan screws indicated by above “
➁
”screw
holes. After the screws are removed pull the stand up toward
the rear of the unit. Be careful not to drop the stand when you
remove it.
If you need to replace these accessories, please refer to the part No. with the illustrations and call our toll free
customer support line found on the cover of this manual.
•
Symbols Used in this Manual
The following is the description for the symbols used in this manual. Description refers to:
TV
: Analog TV operation
DTV
: Digital TV operation
• If neither symbol appears under the function heading, operation is applicable to both.
5
owner’s manual
(1EMN24662)
quick start guide
(1EMN24666)
remote control
(NF015UD)
batteries
(AA x 2)
registration card
(1EMN24700)
cable
management tie
(1EM428657)
Phillips pan screw for
attaching the stand x 4
(FPH34140)
AC power cord
(WAV0162LW001) or
(WAV0162LTE03)
screw holes screw holes
front side
