INTRODUCTION PREPARATION
WATCHING TV
OPTIONAL SETTING TROUBLESHOOTING
INFORMATION
English
6. BACK (p. 16)
Press to return to the previous menu operation.
7. CH RETURN (p. 14)
Press to return to previously viewed channel.
8. VOL.
X
/
Y
(p. 14)
Press to adjust the volume.
9. MUTE
(p. 14)
Press to turn the sound on and off.
10. INPUT SELECT (p. 15)
Press to access connected external devices
like a BD/DVD recorder.
11. SLEEP (p. 14)
Press to activate the sleep timer.
12. AUDIO (p. 15)
Digital mode (DTV)
• Press to select the audio language.
Analog mode (TV)
• Press to select the audio mode.
13. STILL (p. 15)
Press to pause screen image.
14. SCREEN MODE
(p. 17)
Press to select aspect ratio available for the TV screen.
15. INFO (p. 16)
Digital mode (DTV)
• Press to display the channel information, signal type
and TV setting.
Analog mode (TV)
• Press to display the channel number, signal type and
TV setting.
External input mode
• Press to display the external input mode, signal type
and TV setting.
16. CH K/L (p. 14 / p. 15)
P
r
es
s to select channels and the external input mode.
1. POWER (p. 13)
Press to turn the unit on and off.
2. Number buttons (p. 14)
• Press to select channels.
-
(hyphen)
• Press to shift the subchannel from the main channel.
3. SETUP (p. 13)
Press to display the main menu.
4.
s
/
B
/
K
/
L
(p. 13)
Press to move left / right / up / down through the
items.
5. ENTER (p. 13)
Press to decide the command of setting when the
main menu is displayed.
Remote Control Function5
When using a universal remote control to operate
this unit.
• Make sure the component code on your universal remote
control is set to our brand.
Refer to the manual accompanying your remote control for
more details.
• We do not guarantee 100% interoperability with all universal
remote controls.
CH RETURN
Battery Precautions:
• Be sure to follow the correct polarity as indicated in the battery compartment. Reversed batteries may cause damage to the device.
• Do not mix different types of batteries together (e.g., Alkaline and Carbon-Zinc, or rechargeable batteries like ni-cad, ni-mh, etc) or
old batteries with fresh ones.
• If the device is not to be used for a long period of time, remove the batteries to prevent damage or injury from possible battery leakage.
• Do not try to recharge batteries; they can overheat and rupture.
Installing the Batteries
Install the batteries (AA x 2) matching the polarity indicated inside battery compartment of the remote control.
5
