Head unit
1 DISPLAY button
Press to select different displays.
2 PGM button
Press to operate the preprogrammed func-
tions for each source. (Refer to Using the
PGM button on page 95.)
3 Ambient light sensor
Senses ambient light. This system automati-
cally adjusts the brightness of the display to
compensate for ambient light.
4 FLIP DOWN/CLOCK button
Press to turn the LCD panel horizontal tem-
porarily when the LCD panel is upright.
Press to display the clock for eight seconds
when the LCD panel is closed.
5 OPEN/CLOSE button
Press to open or close the LCD panel.
6 ENTERTAINMENT button
Press to switch between the background
displays.
7 WIDE button
Press to select a desired mode for enlarging
a 4:3 picture to a 16:9 one.
8 MENU button
Press and hold to display the picture adjust-
ment menu.
9 RESET button
Press to return to the factory settings (initial
settings).
a DETACH button
Press to remove the front panel from the
head unit.
b EJECT button
Press to eject a disc from this unit.
1
2
4
5
3
6
7
a
c
d
e
f
g
h
i
l
k
9
j
8
b
Whats What
En
15
Section
03
Whats What
