Using the GUIDE Plus+™ electronic program guide
05
46
En
6 Use the number buttons to enter a channel
number, then press the GREEN Action button (Next)
to confirm.
Alternatively, you can press the
YELLOW
Action button
(
Mosaic
) and use the
///
buttons to select a
channel from the mosaic, followed by
ENTER
.
The Info Area
This area is reserved for additional information such as
news, weather reports, stock quotes, and so on, and
varies by region. (Note that this feature is not available in
all countries/regions.)
The Editor Area
The Editor Area is the central location for you to manage
your channels. Any changes you make here will affect
what is displayed in the Grid Area. The Editor Area is
mainly used when setting up the GUIDE Plus+ system to
make any manual changes as necessary.
You can also use the Editor Area if new channels become
available in your area, or if you change from cable to
satellite, say, or move house.
From the Editor Area you can:
• Display/hide channels in the grid (switch the channel
on/off).
• Select a channel source (
Tuner
,
Ext. Rec 1
,
Ext. Rec.
2
, etc.).
• Enter a channel program number.
Switching a channel on/off
You can choose whether or not to display a channel in the
Grid Area by switching the channel on or off in the Editor
Area.
1 Select ‘Editor’ from the Menu bar.
2 Highlight the left channel tile of the channel you
want to switch on or off.
3 Press the RED Action button to switch the
channel on or off.
Changing the source and program number
1 Select ‘Editor’ from the Menu bar.
2 Highlight the right channel tile of the channel
you want to make a change to.
3 Press the RED Action button to change the
channel source, or the GREEN Action button to enter
a program number.
Each press of the
RED
Action button changes the
channel source (
Tuner
,
Ext. Rec 1
, etc.). To set a
program number, use the number buttons to enter a
program number then press
ENTER
. (When set to
Tuner
,
make sure that the program number matches the preset
number of this recorder for what you want to record).
