English - 7
1
SOURCE
Toggles between all the available input sources
(TV, AV1, AV2, S-Video1, S-Video2, Component1,
Component2, PC, HDMI1, or HDMI2).
2
MENU
Press to see an on-screen menu of your TV’s features.
3
+ VOL –
Press to increase or decrease the volume.
In the on-screen menu, use the + VOL – buttons as you
would use the ◄ and ► buttons on the remote control.
4
CH
Press to change channels.
In the on-screen menu, use the CH buttons as you
would use the ▲ and ▼ buttons on the remote control.
5
(ENTER)
Press to confirm a selection.
6
POWER
Press to turn the TV on and off.
7
Remote Control Sensor
Aim the remote control towards this spot on the TV.
8
Indicator Lights
Blinks and turns off when the power is on and lights up in
stand-by mode.
Indicator Light Key
( : On, : Blinking, : Off)
STAND BY/TEMP
TIMER LAMP Indication
Standby state.
The picture will automatically appear in about 15 seconds.
Auto Timer ON/OFF has been set and the set will automatically be turned on in about 15 seconds.
A cooling fan inside the set is not operating normally.
Lamp cover on the side of the set is not properly shut.
Check if the ventilation hole on the side of the set is blocked, because if the inner temperature is
too high, the power will shut off.
Lamp may be defective. Please contact a certified technician.
➢
◆
It takes about 30 seconds for the TV to warm up, so normal brightness may not appear immediately.
◆
The TV has a fan to keep the inside lamp from overheating. You’ll occasionally hear it working.
◆
You can use the channel selection buttons to switch on the TV when it is in standby mode depending on the model.
◆
When using the on-screen menu the volume adjustment and channel selection buttons have the same function as the ▲/▼/◄/►
buttons on the remote control.
◆
If the remote control no longer works or you have lost it, you can use controls on the panel of the TV.
