Color Pro Sub-Menu
ColorPro Sub-Menu
Uses the ColorPro probe to measure the chromaticity and luminance (brightness) of the
test CRT display. The ColorPro probe connects directly to the serial port on the
generator. Chromaticity is shown as C.I.E. x, y coordinates and the luminance (Y) can be shown
in units of either Foot-Lamberts or nits. The ColorPro needs to be over a fully lit white area of
the CRT screen for accurate readings. The Window or Raster patterns are suitable for use with
the ColorPro.
Error Codes: 1, 7 - ColorPro not seeing a usable test image.
5, 8 - Generator did not find a ColorPro probe.
2, 3, 6 - Probe malfunctioning.
Initiates one
reading with the
ColorPro
Toggles between
footlamberts or
nits units
