IM-DR580H
03/10/15 IM-DR580H(E)3.fmIM-DR580H(E) TINSE0568AWZZ
Recording
-Recording from a Microphone/Notes for recording-
To stop recording
Press the button.
Synchro recording is deactivated.
To use the last setting for synchro recording
Press the REC button to pause recording and press the
REC button for 2 seconds or more.
Synchro recording starts.
Synchro recording indicator on the remote control:
You can check the recording status.
Notes:
! Recording may not pause or resume at an appropriate
timing depending on the playback signal from the
microphone. In this case, perform recording manually
(see pages 28 - 29).
! If the unit starts recording from low unwanted noises
too often, set the microphone input to "MIC SYNC L".
Recording pause and track numbering
The unit automatically pauses when the microphone
does not pick up any sound for 3 seconds or more.
(Pause function does not work for approximately 10 sec-
onds after a recording starts.) When the microphone
picks up sound again, recording starts automatically.
Notes for Recording
" To prevent recorded MiniDiscs from being
erased accidentally
Slide the accidental erase prevention tab, located on the
side of the MiniDisc, in the direction indicated by the
arrow.
The MiniDisc will then be protected against accidental
erasure.
To add a recording to such a MiniDisc, slide the acciden-
tal erase prevention tab back to its original position.
" Helpful tip when attaching a label
When attaching a label to a MiniDisc cartridge, be sure to
note the following. If the label is not attached properly,
the MiniDisc may jam inside the unit and you may not be
able to remove it.
Synchro recording indicator
Lit: Recording in progress
Flashing: Paused
! If the label peels off or partially lifts
away, replace it with a new one.
! Do not put a new label on top of an ex-
isting one.
! Attach the label only in the specified
location.
3
