03/10/15 IM-DR580H(E)9.fmIM-DR580H(E) TINSE0568AWZZ
References
-Error Messages-
" A number or symbol appears in (*) position.
" Messages shown in the brackets are shown on the
remote control.
ERROR MES-
SAGES
MEANING
LOCKED " You removed a MiniDisc whilst record-
ing or editing.
(Turn off the power before removing the
MiniDisc.)
NAME FULL
(N-FULL)
" The number of a disc, group, or track
name exceeds 40.
(Shorten the name.)
NO DISC
(NoDISC)
" A disc has not been loaded.
NO SIGNAL
(noSIG.)
" Poor connection of the digital cable.
" No output signal comes out from the
connected unit.
(Use the AC power for the connected unit.)
" The input signal has improper sampling
frequency.
NO TRACK
(NoTRACK)
" There is no track to be played.
PLAY MD
(PLAYmd)
" You tried to record on a playback-only
disc.
POWER? " AC adaptor other than specified.
" Abnormal voltage detected.
PROTECTED " The write protection tab of a MiniDisc is
set to the protected position.
SORRY
(Sorry)
" Since a track number is currently being
located or updated, the unit cannot ac-
cept your command.
(Wait a while and try the operation again.)
ERROR MES-
SAGES
MEANING
TEMP OVER
(TEMP!)
" The temperature is too high.
(Turn off the power, and wait a while.)
TOC FORM
(**)
" There is an error in the recorded signal.
(Erase all of the tracks, and then record
again.)
TOC FULL
(T-FULL)
" There is no space left for recording
character information (track names,
disc names, etc.).
Tr. Protect
(Tr. PRO-
TECT)
" The track has been protected from be-
ing erased.
(Edit the track with the device on which it
was recorded.)
? DISC " A disc which contains data other than
music was played.
(A disc which contains non-music data
cannot be played.)
? Gr Form " The group recording or the GROUP
RESERVE function cannot be per-
formed.
(Erase the disc name and retry the same
operation.)
9
