IM-DR580H
03/10/15 IM-DR580H(E)4.fmIM-DR580H(E) TINSE0568AWZZ
Recording
-Advanced Recording-
Notes:
" Tracks recorded in 2 times long recording and 4
times long recording modes cannot be played with
the unit that does not support these modes. On
such a unit, no sound is heard. (The operation
may vary depending on the unit.)
" Tracks can be recorded in stereo recording mode, 2
times long recording mode, and 4 times long recording
mode on one MiniDisc.
" In monaural recording, the sound on the right and left
channels is mixed even if the input source is in stereo.
Although you can hear the stereo sound from the ear-
phones, the recorded sound is monaural.
" The recording mode remains unchanged until a new
mode is selected.
Caution for 4 times long recording (LP4)
Special compression methods are used to achieve 4
times long recording. This may cause some noise to be
recorded occasionally. When the highest quality is
required, stereo or LP2 recording is recommended.
! About ATRAC
The ATRAC (Adaptive TRansform Acoustic Coding) sys-
tem compresses the sound data into 1/5 by cutting out
the inaudible sound. Since the sound is selected based
on psychoacoustics masking, the sound quality is not
impaired. This unit is equipped with the ATRAC3 com-
pressing system that can reduce the sound data to 1/10
or 1/20 of its original size. By employing this system, 2
times and 4 times long recordings are enabled in stereo
mode.
1
Press the REC button.
2
Press the MODE/-CHARGE
(MODE) button repeatedly to se-
lect the desired recording
mode.
Each press of the button changes
the mode.
For an 80 minute MiniDisc.
Indication Recording mode Recording time
None Stereo MAX. 80 min.
LP2 2 times long (MDLP
stereo)
MAX. 160 min.
LP4 4 times long (MDLP
stereo)
MAX. 320 min.
SP/MONO Monaural MAX. 160 min.
Display on the remote control
Indication Recording mode
Stereo
2 times long (MDLP stereo)
4 times long (MDLP stereo)
Monaural
FlashLight up
Recording mode
3
