SRC-38 SERIES User’s Manual
4
For SRC-3815 Remote Control
IR Out jackConnect the IR
blaster cable to this jack to
operate a specific device.
IR-extender address setting
Set the RF address of the IR-
extender by selecting and
address number between 0 ~ 9.
AC adapter
– Plug AC adapter
into jack and then into AC
outlet.
Remote Locator Button
Press locator button to call
remote control to make beep
signal and locate the remote.
(Only for SRC-3815)
Infrared Emitter
Sends IR
signal, aim at equipment.
IR Blaster Cableattach
directly to equipment that is not
within directional range of IR-
extender. With front and rear
adhesive.
AC Adapter plug into IR-
extender and into AC outlet.
IR Blaster cable with
front and rear adhesive
AC adapter
