Identifying Components
Refer to the following illustration to identify the
components of the SRC-3810/3815.
Infrared Eye: point the
infrared eye at the device you
want to operate.
Light Sensor: detects ambient
light to automatically set the
LCD panel backlight.
QUICK CH: enables you to
group channel types for easy
access.
LCD: backlit LCD emulates the
hard key controls, and
provides a user interface for
the SRC-3810/3815.
Touch Screen: enables you to
change channels, configure
the SRC-3810/3815, create
macros, and more.
Backlight: press this button to
turn on the LCD backlight.
Hard Key: these buttons
enable you to turn the
controlled devices on and off,
change channels, and adjust
or mute the audio volume.
Page/Date: press this button
to browse through the device
screens. Press and hold this
button to display the date and
time.
Device Keys: press these
buttons to display remote
control screens for the devices
listed.
Learning Eye: point your
device's remote control at the
learning eye to enable the
SRC-3810/3815 to learn your
device's infrared codes.
Infrared Eye
Light Sensor
Quick Channel
LCD
Touch Screen
Backlight
Hard Key
Page/Date
Device Keys
Learning Eye
Figure 1: Front View
