36
3. SETUP continued …
3.7 MODE PRESETS
Mode and THX presets are applied when the source is selected or MAIN is turned on. Each input format
except mono and Anlg-Dir has a setting. If you do not want to use presets, set them to Last Used.
After selecting a source in the MODE PRESETS root menu, a menu such as the DVD1 example below
appears. Use the buttons to highlight an input format then use the buttons to select. For
descriptions of surround modes and when to use them, refer to section 4.8.
7f. DVD1 MODE PRESETS
a. 2.0: AnthemLogic-Cin
b.2Sur: PLIIx Movie
c. 6.0: PLIIx Movie
d. DD5: PLIIx Movie
e. EX: PLIIx Movie
f. DTS: Neo:6
g. ES: DTS-ES Matrix
h. 7.1: None
Program Preset Selections
• 2.0 For stereo input, select any mode in section 4.8.3, THX Games Mode, or Last Used. Dolby
Pro Logic, Pro Logic IIx Movie, and Neo:6 Cinema can be set with or without THX Cinema.
• 6.0 Select your playback preference for multichannel PCM (via HDMI) and 6-Ch analog input:
PLIIx Movie (with or without THX Cinema), PLIIx Music, Dolby D EX, THX Surround EX,
THX Cinema, THX Ultra2 Cinema, THX MusicMode, THX Games Mode, Neo:6 (with or
without THX Cinema), Last Used, or None (see sections 4.8.4 and 4.8.6).
The following apply to Digital inputs only:
• 2.0-Sur Separate setting especially for surround-flagged Dolby Digital 2.0 material (section 4.8.2),
normally PLIIx Movie but any setting that applies to regular stereo input can also be used.
• DD-5.1 Select your playback preference for Dolby Digital 5.1 material: PLIIx Movie (with or
without THX Cinema), PLIIx Music, Dolby D EX, THX Surround EX, THX Cinema,
THX Ultra2 Cinema, THX MusicMode, THX Games Mode, Neo:6 (with or without
THX Cinema), Last Used, or None (see sections 4.8.4 and 4.8.6).
• DD-EX For material encoded in Dolby Digital Surround EX: PLIIx Movie (with or without
THX Cinema), PLIIx Music, Dolby D EX, THX Surround EX, Neo:6 (with or without
THX Cinema), Same as DD-5.1, Last Used, or None (see sections 4.8.4 and 4.8.6).
• DTS-5.1 For DTS material: Neo:6 (with or without THX Cinema), PLIIx Movie (with or without
THX Cinema), PLIIx Music, Dolby D EX, THX Cinema, THX Ultra2 Cinema, THX MusicMode,
THX Games Mode, Last Used, or None (sections 4.8.5 and 4.8.6).
• DTS-ES For DTS-ES: DTS-ES Matrix (with or without THX Cinema), PLIIx Movie (with or without
THX Cinema), PLIIx Music, Dolby D EX, Same as DTS, Last Used, or None (see sections
4.8.5 and 4.8.6). Note that for ES Discrete, this setting is overridden and playback is in 6.1.
• 7.1 For HDMI 7.1-channel: THX Cinema, Last Used, or None (see section 4.8.6).
