Adjusting the sound
21
DX-32L221A12/DX-40L260A12
• Reset Picture Settings—Resets all picture settings to
factory mode.
3 Press MENU to return to the previous menu, or press EXIT to
close the menu.
Adjusting the computer image
To adjust the computer image:
1 Make sure that your TV is in VGA mode. For more information, see
“Selecting the video input source” on page 18.
2 Press MENU. The on-screen menu opens.
3 Press
or to highlight SETTINGS, then press . The SETTINGS
menu opens.
4 Press
or to highlight Computer Settings, then press
ENTER. The SETTINGS-Computer Settings menu opens.
5 Press
or to highlight an option, then press or to adjust
the option. You can select:
• Auto Adjust—Automatically adjusts the image settings
such as position and phase.
• H. Position—Moves the image right or left.
• V. Position—Moves the image up or down.
• Clock—Adjusts the sample frequency.
• Phase—Adjusts the focus of stable images.
• Reset Computer Settings—Resets all computer settings
to factory mode.
6 Press MENU to return to the previous menu, or press EXIT to
close the menu.
Adjusting the sound
Adjusting sound settings
To adjust sound settings:
1 Press MENU. The on-screen menu opens.
2 Press
or to highlight AUDIO, then press . The AUDIO menu
opens.
3 Press
or to highlight an option, then press or to adjust
the option. You can select:
• Sound Mode—Selects the picture mode. You can select
Movie, Music, News, Standard, or Custom.
• Treble—Adjusts the high sounds.
• Bass—Adjusts the low sounds.
• Balance—Adjusts the balance between the left and right
audio channels.
• Auto Volume—Automatically adjusts volume to be
consistent across programs and channels.
• Digital Audio/SPDIF—Sends digital audio to an external
audio system. You can select PCM (to select to output audio
in 2-channel stereo), or RAW (to pass through the original
digital audio sound).
• Audio Language—(Digital channels only) Selects an
alternate audio language, if available.
• MTS/SAP—(Analog channels only) Selects the audio mode.
You can select:
• Mono—Select this option if there is noise or static on
weak stereo broadcasts.
• Stereo—Select this option for programs broadcast in
stereo.
• SAP—Select this option to listen to a secondary audio
program, if available.
• Reset Audio Settings— Resets all audio settings to
factory defaults.
4 Press MENU to return to the previous menu, or press EXIT to
close the menu.
Menu Exit
Picture Mode
Backlight
Sharpness
Tint
Color
Brightness
Contrast
Energy Savings
+10
43
0
58
50
50
Move Select Back Exit
Adjust settings to aect picture quality
PICTURE AUDIO SETTINGS CHANNELS
Menu Exit
Parental Controls
Component Settings
Computer Settings
Input Labels
Menu Settings
Time
Closed Caption
Move Select Back Exit
Set various TV options
PICTURE AUDIO SETTINGS CHANNELS
Note
You can also press MTS/SAP one or more times to
select the audio mode.
Menu Exit
Picture Mode
Backlight
Sharpness
Tint
Color
Brightness
Contrast
Energy Savings
+10
43
0
58
50
50
Move Select Back Exit
Adjust settings to aect picture quality
PICTURE AUDIO SETTINGS CHANNELS
Menu Exit
Sound Mode
Audio Language
Digital Audio/SPDIF
Auto Volume
Balance
Bass
Treble
Standard
O
PCM
0
32
32
Move Select Back Exit
Adjust settings to aect sound quality
PICTURE AUDIO SETTINGS CHANNELS
DX-32L221A12-DX-40L260A12_11-0101_MAN.book Page 21 Monday, April 18, 2011 1:22 PM
