OPERATING TV OPERATING DVD SETTING DVDINTRODUCTION PREPARATION
SETTING TV
TROUBLESHOOTING
ESPAÑOLINFORMATION
S
ETTING TV
INITIAL SETTINGS
This section will guide you through your TV’s initial set up which includes
selecting a language for your on-screen menu and AUTOSCAN, which
automatically scans and memorizes viewable channels.
1
After making all the necessary connections, turn on
your TV.
2
Press [POWER] to display the Initial Setup menu.
• This operation may take a few moments.
• If Initial Setup menu does not appear, press and hold
[ENTER] for 3 seconds, initial setup will appear then
proceed to step 3.
If initial set up has already been completed, refer to
“LANGUAGE SELECTION” on page 16.
3
When you first turn on your TV, the following screen is
displayed. Use [
K
/
L
] to select the on-screen menu lan-
guage from the choices on the right side of the screen.
(English / Español / Français)
or
Initial Setup
Initial Setup
Select the language for setup display.
Elija idioma de preparación.
Sélectionner langue écran config.
Select Enter Exit
SETUP
Español
Français
ENTER
English
• The Antenna Confirmation menu on step 4 will be
displayed in the selected language after you press
[ENTER].
4
Use [
K
/
L
] to select source of ANT. IN jack, then press
[ENTER].
or
Initial Setup
Initial Setup
Air
Cable
Select Enter Exit
SETUP
Back
BACK
ENTER
Make sure the antenna is connected to "ANT IN" jack.
Select the destination of "ANT IN" jack.
Air
Cable
Or
ANT IN
5
Autoscan will start automatically.
Initial Setup
Initial Setup
Now the system is scanning for channels,please wait.
Exit
SETUP
5%
Analog channels 1ch
Digital channels 0ch
• When scanning has completed, the lowest memorized
channel will be displayed.
5
NOTE:
• The initial Autoscan function can be executed for either “Air”
or “Cable” only once. When you change the connection (Air/
Cable), set the “Autoscan” again. (Refer to page 14.)
• If you connect to the cable system directly, contact the CATV
installer.
• When the scanning is not complete, Helpful Hint will be dis-
played every time you turn on the power. If you have previ-
ously registered channels when this screen appears, you can
access them with [the Number buttons].
No channel is registered.
Press and hold "ENTER" key for 3 seconds.
Contact support hotline provided on manual or back of unit.
Sin canal registrado.
Mantenga oprimida la tecla "ENTER" durante 3 segundos.
Llame teléfono de apoyo en manual o atrás de TV.
Pas de chaîne consign.
Maintenir la touche "ENTER" pressée 3 secondes.
Contacter numero d'urgence dans manuel ou arrière appareil.
2-0
• Toll free customer support line can be found on the cover of
this manual.
TV FUNCTIONS
