EN
O
PERATING DVD
MP3, JPEG PLAYBACK
MP3 JPEG
MP3 or JPEG is a method of compressing les. You can copy MP3 or JPEG
les on CD-RW/-R discs from the Personal Computer and play the les on
this unit.
1
Insert an MP3 or JPEG-format disc, playback starts
automatically.
• Press [PLAY B] if MP3 or JPEG-format disc is already
inserted.
• Press [DISC MENU] when you want to call up the FILE
LIST.
When selecting the folder:
• Press [ B] when you want to go to the next hierarchy.
or
folder name 4
folder name 1
folder name 3
folder name 2
folder name 1
DISC NAME
FILE LIST
FOLDER
MP3
ENTER
PLAY
file name 1
file name 2
file name 1
1/ 2
JPEG
• Press [s] when you want to go back to the previous
hierarchy (except for the top hierarchy).
• If [TITLE] is pressed when a FILE LIST is displayed, the
1st item in the top hierarchy will be highlighted.
• Press [DISC MENU] or [BACK/RETURN] to go back to
playback display.
2
Press [STOP C] once to stop playback temporarily.
• Refer to “RESUME“ on page 30.
NOTE:
• Some selections may take a while to be recognized.
• Folders are known as Groups; files are known as Tracks.
• Folders, MP3 files and JPEG files are displayed respectively as
, and .
• A maximum of 255 folders or 999 files may be recognized in
one disc.
• Up to 8 hierarchies can be recognized in one folder. Files in the
9th or deeper hierarchies cannot be played back.
• This unit can play back images and sounds from data recorded
in MP3 and JPEG formats on CD-RW/-R discs.
• A file with an extension of “.mp3 (MP3)” is called an “MP3 file”.
• A file with an extension of “.jpg (JPG)” or “.jpeg (JPEG)” is called
a “JPEG file”.
• The unit can run an image file conforming to the Exif specifi-
cation. Exif is a file format, Exchangeable Image File format
established by Japanese Electronic Industry Development
Association (JEIDA).
• Files whose extension is other than “.mp3 (MP3)”, “.jpg (JPG)”
and “.jpeg (JPEG)” will not be listed in the MP3 or JPEG menu.
• If the file is not recorded in MP3 or JPEG format, noise may be
produced even if the file extension is either “.mp3 (MP3)”, “.jpg
(JPG)” or “.jpeg (JPEG)”.
• The name of group and track can be displayed in up to 25 char-
acters. Unrecognizable characters will be replaced with asterisks.
• Unplayable groups or tracks may be displayed depending on
the recording conditions.
• Progressive JPEGs (JPEG files saved in the progressive format)
will not play on this unit.
5
This unit recommends the files recorded under the follow-
ing circumstances:
Applicable MP3 le Remarks
Sampling frequency:
44.1 kHz or 48 kHz
For MP3 file recorded in Variable Bit
Rate (VBR), the unit may not display
the actual elapsed time.
Constant bit rate:
32 kbps ~ 320 kbps
Applicable JPEG le Remarks
Normal playback
Upper limit: 6,300 x 5,100 dots
Lower limit: 32 x 32 dots
File size: Max. 7 MB
A JPEG image that extends beyond
the screen is reduced so that it will
be displayed within the screen.
Dual playback
Upper limit: 5,000 x 5,000 dots
Lower limit: 32 x 32 dots
File size: Max. 5 MB
DUAL PLAYBACK
MP3 JPEG
This function lets you play back MP3 and JPEG les simultaneously. Avail-
able only when “Dual Playback” is “ON“. See page 43 on how to set the Dual
Playback ON or OFF.
1
Press [PLAY B], then press [DISC MENU].
folder name 4
folder name 1
folder name 3
folder name 2
folder name 1
DISC NAME
FILE LIST
FOLDER
MP3
ENTER
PLAY
file name 1
file name 2
file name 1
1/ 2
JPEG
2
When playing back an MP3 file, use [K / L] to select a
desired JPEG file from the FILE LIST, then press [ENTER]
(or [PLAY B]).
or
or
• When playing back a JPEG file, select an MP3 file.
NOTE:
• To cancel Dual Playback, press [DISC MENU] again at step 1.
• If you press [PLAY B] directly after you inserted a disc which con-
tains both MP3 tracks and JPEG files and if the “DUAL PLAYBACK”
setting is “ON”, Dual Playback will start automatically.
• If you press [FWD D] or [REV E] during Dual Playback, a
JPEG file will be paused.
• Zooming or rotating a JPEG file during Dual Playback may
cause an intermittent sound.
• Depending on the data size of each file, Dual Playback may not
function properly. (Refer to “Applicable JPEG file” on page 32.)
5
