RQT8203
Control reference guide
Instructions for operations are generally described using the remote control.
∫ Smart Wheel operation
1 Turn the unit on (➡ 18, 19)
2 Direct TV recording (➡ 25)
3 Select drive (HDD, DVD or SD) (➡ 22, 30, 34)
4 Select channels and title numbers, etc./Enter numbers
5 Cancel
6 Basic operations for recording and play
7
Show timer recording programme screen
(➡ 28)
8 Smart Wheel (➡ below)
9 Show Top menu/Direct Navigator (➡ 30, 31, 38)
: Show sub menu (➡ 38)
; Show status messages (➡ 37)
< Colour buttons for switching between Video/Picture and Video/
Playlists, selecting character type when entering text, manual
tuning settings and GUIDE Plus+ operations
§
(➡ 30, 45, 53, 58)
= Show on-screen menu (➡ 36)
> Start recording (➡ 22)
? Change recording mode (➡ 22)
@ Skip the specified time/Display the television image as a picture-
in-picture (➡ 25, 32)
A Select audio (➡ 32)
B Transmission window
C Television operations (➡ 21)
D Channel select/Change pages in the GUIDE Plus+ system
§
(➡ 22)
E Show S
HOWVIEW screen (➡ 26)
F Input select (AV1, AV2, AV3, AV4 or DV) (➡ 25, 47)
G Skip 30 seconds forward (➡ 32)
H Show the GUIDE Plus+ screen (➡ 18, 26)
I Show programme information in the GUIDE Plus+ system
§
J Show FUNCTIONS window (➡ 37)
K Return to previous screen
L Create chapter (➡ 32)
M Erase items (➡ 32)
N Timer recording standby/release (➡ 26–28)
O Linked timer recordings with external equipment (➡ 29)
P Flexible Recording (➡ 24)
Q One touch transfer (dubbing) (➡ 44)
R Recording functions
§
Refer to the “User’s manual for the GUIDE Plus+ system” for more
information.
[Note]
≥Buttons such as the [¥ REC] button do not protrude as much as
other buttons to stop them from being pressed accidentally.
≥If you press [EXT LINK] accidentally, the unit turns off and switches
to recording standby mode. Press [EXT LINK] again to cancel
recording standby.
≥The word “button” is not used in these operating instructions so
“Press the [ENTER] button.” is shown as “Press [ENTER].”
≥You can use this remote control to operate your television if you set
the television manufacturer code (➡ 21).
Remote control
≥Select items on menu screens and set items.
These operations are also possible…..
≥Frame-by-frame (backward/forward/):
While paused, press [2;] or [;1] (left/right)
≥Search (forward/backward):
During play, turn right or turn left
≥Slow-motion (forward/:backward):
While paused, turn right or turn left
[Note]
Press the Smart Wheel lightly when turning it.
If you press it strongly when turning it, [3, 4, 2, 1] may be
mistakenly activated.
DVD
HDD
HDD
DVD
DVD
SD
SD
1
2 3
4 5 6
7
8
9
G
U
I
D
E
F
U
N
C
T
I
O
N
S
Í
Í
DIRECT TV REC
AV
CH
VOLUME
TV
TV
PAG E
CH
ShowView
MANUAL SKIP
0
INPUT SELECT
SKIP
SLOW/SEARCH
STOP
PAU SE
PLAY/x1.3
N
A
V
I
G
A
T
O
R
D
I
R
E
C
T
P
R
O
G
/
C
H
E
C
K
SUB MENU
RETURN
DISPLAY
STATUS
CREATE
CHAPTER
ERASE
REC
REC MODE
EXT LINK
TIMER
TIME SLIP
AUDIO
DUBBING
F Rec
DVD/TV
DVD/TV
ENTER
ENTER
CANCEL
T
O
P
M
E
N
U
S
C
D
E
F
G
B
I
J
K
L
M
H
1
2
3
4
5
6
7
8
9
:
;
<
=
>
@
A
?
N
O
P
Q
R
ENTER
ENTER
Press [3, 4, 2, 1] (up, down, left or right) to select an item.
Press [ENTER] to confirm.
You can also turn the wheel to select an item.
