Pioneer DVR-440H-S DVD Recorder User Manual



The Initial Setup menu
14
118
En
Manual CH Setting Next Screen
Proceed to the next screen if you need to adjust any
of the settings made by auto tuning. Select your
country, then proceed to the manual channel setting
screen:
• Change channel presets using the
/
buttons.
• To skip the displayed channel (because there is no
station assigned to that channel), change the
Skip
setting to
On
.
• Set the
CH SYSTEM
setting to match the channel
system of your country or region.
• Set the
CHANNEL
setting to the channel you want
to assign to the current channel preset.
• To manually fine tune the channel, change the
AFT
setting to
Off
then adjust the
Level
setting.
• Set the
Sound System
setting to match the sound
system of your region.
• The
Name
field allows you to input a name of up to
five characters for the current channel preset.
• If the currently selected channel is scrambled
requiring a decoder connected to the
AV2 (INPUT 1/
DECODER)
, set the
Decoder
setting to
On
.
Channel Swapping Next Screen
Proceed to the next screen to swap channel
assignments of different presets so that you can
group together presets that naturally go together.
Select two presets to swap then press
ENTER
.
Video In/Out
Input Colour
System
Next Screen
Proceed to the next screen to set the input colour
system for the external input and the built-in TV
tuner. Use the
CH +/–
buttons to change the preset.
On the default
Auto
setting the recorder can gener-
ally correctly detect whether the input signal is PAL,
SECAM, 3.58 NTSC or PAL-60, but in some cases you
may have to set it manually if the picture is displayed
incorrectly.
See also About the input colour system on page 128 for more information on this setting.
Setting
Options Explanation
