Pioneer DVR-440H-S DVD Recorder User Manual



Playback
07
80
En
The example displays below show high-
speed copying from HDD to DVD, and HDD
chase playback.
Tip
See
Switching camera angles
on page 79
for more on multi-angle scene
switching.
When using the simultaneous play and
record feature, the display shows
information for playback only.
During real-time copy, the copy source
playback information is displayed.
The Video mode disc displays become
the same as a DVD-Video disc once the
disc is finalized.
The total recording time figure shown in
parenthesis is calculated based on a
12 cm / 4.7 GB disc at the displayed
record setting.
Recording and playback times for TV
recordings are approximately 0.1 %
shorter than the actual time. This is
because of the slightly different frame
rates of TV broadcasts versus DVD.
The frame number is shown next to the
elapsed time display when the disc is
paused.
Copy Once
or
Can’t Record
messages
may appear in the stop or recording
displays. These indicate that the
broadcast TV program contains copy
control information.
Rec Mode SP(2h00m/DVD)
HDD
Remain 10h35m
Stop
Remain –h––m
Stop
Hi-Speed Copy
HDD DVD
0h08m left
DVD-RW Video
Rec Mode SP(2h00m/DVD)
HDD
Remain 10h35m
Chase Play
Rec
Remain 0h52m
Stop
DVD-RW Video
Relative playback position
Recording time
Stop
DVD-RW VR
Original
Disc Name :Comedy shows
DVD Mode
Finalized
Resume
XP (1h00m/DVD)
Rem. 0h35m Copy Once
Stereo
ABC Pr 1
Shows recording restrictions for
the current channel program
Play
DVD-R Video
Title Name 21/11 Football match:
Chapter Total

Chapter Time
3–2 0. 00. 15 !
0. 00. 21
0h01m52s
4.32Mbps
Indicates copy-protected material
Indicates a multi-angle scene
Indicates the data transfer rate
