English _31
! SETUP
Camera Setup
See the previous section to repeat steps 1~3. (Page 30)
Use the up/down (
$%
) button to select <CAMERA
SETUP>, and press [OK].
The “CAMERA SETUP” screen appears.
Use the up/down (
$%
) button to move to a desired item.
CHANNEL: Select a channel to change the title.
TITLE: Move the cursor to the input box and use the
[OK, +, -] buttons to enter a name. (8 characters)
BRIGHTNESS: Adjust the screen brightness.
CONTRAST: Adjust the color contrast.
SATURATION: Adjust the saturation.
HUE: Adjust the color tone.
HORIZONTAL POSITION: Adjust the horizontal position for each channel screen.
LIVE DISPLAY: Turn on/off the Live screen.
If you select <OFF>, the Live screen will not be displayed but the recording proceeds normally.
When done, select <OK>.
Your setting will be applied.
If you select <DEFAULT>, the selected channel will be reset to the default, and if selecting
<ALL-DEFAULT>, all the channels will be reset to the factory default.
To return to the previous menu, select <ESC>.
4.
5.
~
~
~
~
~
~
~
~
`
6.
7.
CONFIGURATION
ESC
HDD MANAGEMENT
CAMERA SETUP
MOTION SETUP
ALARM SETUP
INTERVAL SETUP
DATE/TIME SETUP
PASSWORD SETUP
BUZZER SETUP
HORIZONTAL POSITION: Adjust the horizontal position for each channel screen.
DEFAULT ALL-DEFAULT ESC
CHANNEL CH1
TITLE CAM01---
BRIGHTNESS 0
CONTRAST 10
SATURATION 4
HUE -32
HORIZONTAL POSITION 0
LIVE DISPLAY ON
OK
CAMERA SETUP
02489A_SHR-3040_ENG.indb 31 2009-11-10 오후 2:13:40
