Learning Method
BASIC SETUP
BASIC SETUP
Learning Method
STEP 5:
Press any button on the RF20
that you want to teach a
command to. The top of the
screen will change to “READY”
and the bottom of the screen will
display the button name you
pressed.
STEP 6:
Press and hold the button on the
other remote control that you
want to ‘teach’ to the RF20 until
the LCD display on the RF20
changes to either “GOOD” or
“FAILD”. If the “GOOD” label
appears on top of the display,
you were successful. If the
“FAILD” label appears on top
of the display, try ‘teaching’ the
same button to the RF20 once
again by repeating STEPS 5
and 6.
STEP 7:
Now, continue to teach the RF20
any other commands from your
other remotes by repeating
STEPS 4 through 6 (to go
back to STEP 4, simply press
MAIN once).
STEP 8:
Once you have completed
teaching all the button
commands to the RF20, return to
normal operation by pressing the
MAIN button twice.
• Move to another room. Plasma
TVs, sunlight, halogen or quartz
lighting can interfere with the
learning process.
• Even though the old remote
seems to be working fine, put in
fresh alkaline batteries.
• Gradually vary the distance
between the remote controls.
Try 1”, 2” and so on,
up to 4 feet.
• Try tapping the button on your
old remote instead of pressing
and holding it during the
learning process.
Some additional Information
regarding the Learning Process:
• Learned functions override
any existing pre-programmed
functions on the remote control.
• All buttons can be learned
except for the PAGE, MAIN
and LIGHT buttons.
• Learned functions are
automatically erased when
a new function is learned on
the same button.
• Learned functions are retained
even after a different Setup
Code Number is programmed
into the remote.
• To return to an original
pre-programmed function, a
learned function must be erased.
NOTE: If you don't see the display
button you would like to teach on
the LCD screen, use the PAGE
(
) ( ) buttons. The only
buttons you can't teach are the
PAGE and MAIN buttons.
NOTE: Test all your new commands.
If any of them don’t work, try the
Learning Method again, following
these suggestions:
