Favorite Channel Setup
CUSTOMIZING
CUSTOMIZING
MacroPower
™
Setup
STEP 7:
Press the LIGHT button after you
enter the channel number.
A new screen appears displaying
SAVE, UNDO or EXIT.
STEP 8:
To save the channel you
entered, press the SAVE display
button. The UNDO display button
lets you erase the last entry. The
EXIT display button erases all
entries for this button.
STEP 9:
When you are finished setting
up Favorite Channel buttons,
press the MAIN button twice to
return to normal operation.
STEP 1:
Press and hold the MAIN and
ENT (Enter) buttons at the same
time for approximately 3 seconds,
until the word “SETUP” is
displayed at the top of the LCD
touch screen. This signals that
you are now in setup mode.
STEP 4:
Press the first component dis-
play button you want the Macro
to turn on (in this example, TV)
and “TV” will display at the top
of the screen and “STEP 1” at
the bottom.
STEP 5:
Then, press the ON button to
confirm the command and “STEP
2” will display at the bottom of
the screen. (NOTE: Whenever a
button is pressed, another
Macro step is counted and dis-
played at the bottom of the
screen.)
STEP 6:
Now, press the MAIN button to
return to the Main Component
listing. (“STEP 3” will display at
the bottom of the screen.)
STEP 2:
Press the MACRO display button
on the LCD screen. The top of
the screen will display
“MACRO”. The bottom of the
display will flash “SELECT”.
STEP 3:
Press the ON button. “ON” will
display at the top of the LCD
screen. “STEP0” will display at
the bottom of the screen indicating
that no macro steps have
been entered yet.
MacroPower™ Setup
MacroPower™ is a unique feature that enables you to turn
all of your Components ON or OFF, at the same time, simply
with the press of one button.
We call that a “Macro”. What would normally take multiple
remotes and button pushes, the RF20 can accomplish with
the press of one button. In addition to the Power ON or OFF
buttons, any of the Display buttons (on any Component or
Page) can be set to be Macro buttons as well. Feel the
power!
To setup a Power ON macro button that will turn ON several
components at the same time (for example, TV, VCR and
CABLE), follow these easy steps:
IMPORTANT: You now have 30 seconds to
perform the next step while you are in
SETUP mode. If you don’t press a button
within 30 seconds, SETUP will disappear
from the screen, signaling that you have
exited setup mode and you will need to
start over.
SAVE
BUTTON
