AXIS 243Q Blade - Technical specifications
General performance considerations
When setting up your system, it is important to consider how various settings and
situations will affect performance. Some factors affect the amount of bandwidth (the bit
rate) required, others can affect the frame rate, and some will affect both. If the load on the
CPU reaches its maximum, this will also affect the frame rate.
The following factors are among the most importan
t to consider:
• High image resolutions and/or lower compression
levels result in larger images.
Bandwidth affected.
• Access by large numbers of Motion JPEG and/or
unicast MPEG-4 clients. Band-
width affected.
• Simultaneous viewing of different streams
(resolution, compression, etc.) by dif-
ferent clients. Frame rate
and bandwidth affected.
• Accessing both Motion JPEG and MPEG-4 video streams
simultaneously. Frame
rate and bandwidth affected.
• Heavy usage of event settings affects the CPU load. Frame rate affected.
• Enabled motion detection. Frame rate
and bandwidth affected.
• Heavy network utilization due to poor infrastructure. Bandwidth affected.
• Viewing on poorly performing client PC lowers
perceived performance. Frame
rate affected.
Optimizing your system
To see the bandwidth and frame rate currently required by the video stream, the AXIS
243Q Blade provides a tool that can be used to display these values directly in the video
image.
To do this, special format strings are added as part
of
a text overlay. Simply add #r (average frame
rate in fps) and/or #b (average bandwidth in Kbps)
to the overlay.
For detailed instructions, please see the online help
for Video &
Image > Overlay Settings, and the
help for File Naming & Date/Time Formats.
Important!
•The figures displayed here are the values as delivered by the server. If other restrictions are
currently in force, (e.g. bandwidth limitation) these values might not correspond to those
actually received by the client.
•For Motion JPEG, these values will only be accurate as long as no frame rate limit has been
specified.
