Operations MediaVault 4105 User Manual
5-4
MV 4105_Ciprico Inc.
TABLE 5-2. Description of the Front Panel Components.
Component Description
Power
“On” indicates that the unit is powered up and ready for operation.
This indicator will flash rapidly for 20 seconds during the initial power-on self-test.
RAID 3
“On” indicates that the MV 4105 is operating in a RAID 3 protected mode. See the
“Mode (RAID Type) Functions” section in this chapter for additional RAID type
information.
When this indicator is off, the MV 4105 is operating in RAID 0 (performance) mode.
D1 to D5 (Drive 1
to Drive 5)
These LEDs indicate drive activity or drive fault.
The LEDs will illuminate as the disk drives are being accessed. The LEDs are off
when there is no drive activity.
In a fault condition, associated with the Service LED and an audible alarm, the faulty
drive is identified by a slow blinking drive LED.
4Gb
“On” indicates that the Fibre Channel interface is operating at its optimum 4Gbit
speed.
When this indicator and the 2Gbit indicator are off, the MV 4105 is operating at less
than 2Gbit speed.
2Gb
“On” indicates that the Fibre Channel interface is operating in 2Gbit speed.
When this indicator and the 4Gbit speed indicator are off, the MV 4105 is operating at
less than 2Gbit speed.
Service
“On” indicates that the MV 4105 needs to be serviced. Normally this LED is
associated with an audible alarm. One of the drives LED will flash slowly. A drive
replacement might be necessary. See the “Audible Alarm” section on page 5-14.
