26 VRX756VD
280-8207-00
English
Owner’s manual
Basic Operations
Adjusting the MID
The MID gain, MID frequency (center
frequency) and MID Q can be adjusted as
follows.
1. Press the [ADJ] button, then touch the
[AUDIO] key.
2. Touch the [MID] key.
3. When the bass type selection screen is
displayed, touch the key for the desirable
type to select it.
4. Touch the [w] or [z] key to adjust to
desirable level.
GAIN : –6 to 6 (The factory default setting
is “0”)
FREQ. : 700Hz/1kHz/2kHz (The factory
default setting is “1k”)
Q:1.5/2 (The factory default setting is
“2”)
5. Touch the [RTN] key, [ESC] key, or press the
[ADJ] button.
Adjusting the TREBLE
The treble gain and treble frequency (center
frequency) can be adjusted as follows.
1. Press the [ADJ] button, then touch the
[AUDIO] key.
2. Touch the [TREBLE] key.
3. When the bass type selection screen is
displayed, touch the key for the desirable
type to select it.
4. Touch the [w] or [z] key to adjust to
desirable level.
GAIN : –6 to 6 (The factory default setting
is “0”)
FREQ. : 8kHz/12kHz (The Factory default
setting is “12K”)
5. Touch the [RTN] key, [ESC] key, or press the
[ADJ] button.
Adjusting the non fader output
volume
You can adjust the volume output from the unit’s
non fader output terminal.
1. Press the [ADJ] button, then touch the
[AUDIO] key.
2. Touch the [NON FADER VOL] key.
3. Touch the [w] or [z] key to adjust to
desirable level.
∗ The factory default setting is “0”. (Setting
range: –6 to 6)
4. Touch the [RTN] key, [ESC] key, or press the
[ADJ] button.
Turning on/off the MAGNA BASS
EXTEND
The MAGNA BASS EXTEND does not adjust
the low sound area like the normal sound
adjustment function, but emphasizes the deep
bass sound area to provide you with a dynamic
sound.
1. Press the [ADJ] button, then touch the
[AUDIO] key.
2. Thouch the [M•B EX] key.
Each time you touch the [M•B EX] key, you
can switch between “ON” and “OFF”. When
the MAGNA BASS EX effect is turned on,
“M•B EX” lights in the display.
3. Touch the [RTN] key, [ESC] key, or press the
[ADJ] button.
