Installation and Wire
connection manual
74 VRX756VD
280-8207-00
■ Sample System 2
(VCZ625)
(DVH940)
(TTX7501z
/TTX7504z)
(SRK5)
(SRV303)
(APA4320)
VTR
VRX756VD
TV Tuner
CeNET cable
(included
the TV tuner)
RCA video cable
(included the TV tuner)
CeNET DVD Changer
CeNET cable
(included the VCZ625)
5.1 ch Surround
Decoder
CeNET cable
(included the
DVH940)
Front
Speakers
4-Channel
Amplifier
Rear
Speakers
Center speaker
built-in amplifier
Powered sub-woofer
built-in amplifier
(Black)
Digital optical fiber cable (included the DVH940)
RCA cable
(sold separately)
RCA cable
(sold separately)
RCA cable (sold separately)
Digital optical fiber cable
(
DCA-005/008,
sold separately)
Set the [SLAVE/STAND ALONE]
switch to the [SLAVE] position.
Set the [CeNET/STAND ALONE] switch to
the [CeNET] position.
(Glay)
(Glay)
RCA video cable (included the VCZ625)
Ferrite clamp
(Included the DVD changer)
RCA cable
(included the
DVH940)
Red
White
Non fader
output
Visual input
RCA cable
(sold separately)
Note:
• When the DVD changer (VCZ625) is connected
via optical cable, no sound will be output if AUDIO
OUT is switched to ANALOG on the changer’s
“GENERAL SETUP” menu.
