Owner’s manual
280-8207-00
VRX756VD 53
TV Operations
TV functions
When an optional TV tuner is connected through
the CeNET cable, this unit controls all TV tuner
functions. To watch TV requires a TV tuner.
WARNING
For your safety, the driver should not
watch the TV or operate the controls while
driving. Please note that watching and
operating the TV while driving are
prohibited by law in some countries.
Watching TV
Note:
•For your safety, the VRX756VD has a safety
function which turns off the picture when the car
is moving, so only the audio can be heard. The
picture can only be watched when the car is
stopped and the parking break is applied.
1. Press the [SOURCE] button and select the
TV mode.
2. Press the [BAND] button to select the
desired TV band (TV1 or TV2). Each time the
button is pressed, the input selection toggles
between TV1 and TV2.
3. Press the [d] or [a] button to tune in the
desired TV station.
∗ When the panel is open, the same operation
is also available by using the [å] or [∂]
key.
Watching a video
The TV tuner has a VTR input terminal to which
1 external device can be connected. Connect a
12V video cassette player (VCP) or video
cassette recorder (VCR) to the TV tuner input
terminal.
1. Touch the screen to display the menu, then
touch the [SUB] key.
2. Touch the [EXTRA SELECT] key in the
menu screen when the “VTR” is displayed.
3. To return to the TV broadcast, touch the
screen again and touch the [EXTRA
SELECT] key in the menu screen.
Seek tuning
1. Press the [BAND] button and select the
desired TV band (TV1 or TV2).
∗ The same operation can be performed by
touching the screen to display the menu
screen, then touching the [BAND] key.
∗ If “MANU” is lit in the display, press and hold
the [BAND] button for 1 second or longer.
“MANU” in the display goes off and seek
tuning is now available.
2. Press the [d] or [a] button to automatically
seek a station. Press the [d] button to
automatically tune up the frequency band to
the next available TV station; press the [a]
button to automatically tune down.
∗ The same operation can be performed by
touching the screen to display the menu
screen, then touching the [å] or [∂] key.
Selecting with a station number
Note:
• Cannot be used when TV tuner TTX7504z is
connected.
1. Touch the screen to display the menu, then
touch the [SRCH] key.
2. Touch the [0]~[9] key corresponding with the
station you desired. When you touch the
wrong number ([0]~[9] key), you can cancel
that to touch the [CLR] key.
3. Touch the [ENT] key. The radio station you
required would be tuned.
4. Touch the [ESC] key.
Manual tuning
There are 2 ways available: Quick tuning and
step tuning. When you are in the step tuning
mode, the frequency changes one step at a
time. In quick tuning mode, you can quickly tune
the desired frequency.
1. Press the [BAND] button and select the
desired band. (TV1 or TV2)
∗ The same operation can be performed by
touching the screen to display the menu
screen, then touching the [BAND] key.
∗ If “MANU” is not lit in the display, press and
hold the [BAND] button for 1 second or longer.
“MANU” appears in the display and manual
tuning is now available.
2. Tune into a station.
●Quick tuning:
Press and hold the [d] or [a] button for 1
second or longer to tune in a station.
