ENGLISH
7
LOADING DISCS
2 Set discs in the disc tray with the labeled (printed) side facing up.
Inner disc guide
(8 cm disc)
Disc tray
NOTE:
• Do not move the DVD-3910 while a disc is playing. Doing
so may scratch the disc.
(1) Opening and Closing the Disc Tray
q Turn on the power.
w Press the OPEN/CLOSE button.
Disc tray
OPEN/CLOSE button
NOTES:
• Be sure to turn on the power before opening and closing
the disc tray.
• Do not strike on the button with a pencil, etc.
(2) Loading Discs
• Pick up the disc carefully so as not to touch the signal surface
and hold it with the labeled side facing up.
•With the disc tray fully open, set the disc in the disc tray.
• Set 12 cm discs in the outer disc guide (Figure 1), 8 cm discs in
the inner disc guide (Figure 2).
•Press the OPEN/CLOSE button. The disc is automatically
loaded.
• The disc tray can also be closed automatically to load the disc
by pressing the PLAY button.
Figure 1
Outer disc guide
12 cm disc
Figure 2
Inner disc guide
8 cm disc
NOTES:
• If a foreign object is caught in the disc tray during closing,
simply press the OPEN/CLOSE button again and the tray
will open.
• Do not press the disc tray in by hand when the power is
off. Doing so will damage it.
• Do not place foreign objects in the disc tray. Doing so will
damage it.
Outer disc guide
(12 cm disc)
Power switch
