When “DENON LINK” is selected:
OFF (Factory default)
Digital audio signals are not output from the DENON LINK terminal.
2nd
Set this when the amplifier to be connected by DENON LINK 2nd.
If you connect the DENON LINK, set to 2nd.
When the DENON LINK 2nd connection, Super audio CD’s signals
are not output from the DENON LINK connector. Please use the
analog output terminals or the IEEE1394 connection.
When the DENON LINK connection, could be output 192-
176kHz/24bit 2ch sources or 96kHz/24bit 6ch sources.
When the DENON LINK is set, the down mixed audio signals are
output only from the Left and Right and Front Left and Front Right
terminals.
r
When “IEEE1394” is selected:
OFF (Factory default)
Digital audio signals are not output from the IEEE1394 terminal.
ON
B
When “ON” is selected:
This will lead to the “AUTO PLAY”, and “AUDIO FORMAT”
setting screens. Select the item to be set using the (
•
,
ª
) cursor
buttons and press the ENTER button.
No audio signals are output from the analog connectors when
IEEE1394 is set.
B
Auto Play
Set this when automatically playing this unit from another device,
under circumstances in which this unit is used in conjunction with
a DENON device that supports IEEE1394.
B
Audio Format
Set this format of audio signals from IEEE1394 connector.
B
Auto Play Setting Method
OFF (Factory default)
Set this when you do not wish to control the operation of this unit
from another device.
ON
Set this when you wish to control the operation of this unit from
another device.
B
Audio Format Setting Method
FORMAT 1 (Factory default)
Set this when you conjunction with a DENON device.
FORMAT 2
This is a mode for future system expansion.
IEEE1394 indicator in the display
When “IEEE1394” set to “ON”, this indicator lights as bellow.
flashing..............self check of IEEE1394 connections.
light ...................IEEE1394 connection is OK.
slow flashing.....IEEE1394 connection is NG. (Loop
connection) confirm the connection.
fast flashing ......IEEE1394 connection is NG. confirm the
connection.
DECISION:ENTER BUTTONSELECT :
DIGITAL INTERFACE SETUP
EXIT SETUP
HDMI/DVI BLACK LEVEL
OFF
2nd
HDMI AUDIO SETUP
DENON LINK
IEEE1394
DECISION:ENTER BUTTONSELECT :
DIGITAL INTERFACE SETUP
EXIT SETUP
HDMI/DVI BLACK LEVEL
OFF
ON
HDMI AUDIO SETUP
DENON LINK
IEEE1394
I EEE1394 SETUP
I EEE1394 SETUP
AUTO PL AY
AUDI O FORMAT
OFF
FORMAT 1
DECISION:ENTER BUTTON
SELECT :
✽ To exit the setup mode
Use the
ª
cursor button to select “EXIT SETUP”, then press the ENTER
button. It is also possible to quit by pressing the SETUP button on the remote
control unit.
I EEE1394 SETUP
I EEE1394 SETUP
AUTO PL AY
AUDI O FORMAT
OFF
ON
DECISION:ENTER BUTTON
SELECT :
I EEE1394 SETUP
I EEE1394 SETUP
AUTO PL AY
AUDI O FORMAT
FORMAT1
FORMAT2
DECISION:ENTER BUTTON
SELECT :
