Specifications
33
Specifications
Poor color or no color • Station or cable TV are experiencing
problems. Tune to another station.
• Make sure channels are set into memory.
• Check picture control adjustments.
• Check antenna or cable TV connections
and reorient the antenna.
• Check for sources of possible
interference.
Picture wobbles or
drifts
• Station or cable TV are experiencing
problems. Tune to another station.
• Make sure channels are set into memory.
• Cable TV company is scrambling signal.
• Check antenna orientation.
No cable TV reception • Check all cable TV connections.
• Set Signal Type option to the Cable
mode.
• Station or cable TV system problems. Try
another station.
Horizontal or diagonal
bars on the screen
• Check antenna connections, reorient
antenna.
• Check for sources of possible
interference.
No reception above
channel 13
• Make sure Signal Type option is in the
appropriate mode.
• If using an antenna, check UHF antenna
connections.
TV turns off • No broadcast on station tuned.
•The Sleep Timer is set.
• The power has been interrupted.
Closed captioning
does not work
• The TV station is experiencing problems
or the program tuned is not closed
captioned. Try another channel.
• Check cable TV connection or VHF/UHF
antenna, then reposition or rotate the
antenna.
• Set closed captioning in the menu.
Display is not shown in
your language
• Select the correct language in the menu
options.
Picture has a few
bright or dark dots
A few bright or dark dots on an LCD screen is
normal. It does not affect the operation of
this TV.
DVD problems
Playback does not
start
•No disc is inserted.
• The disc may be dirty. Clean the disc.
• The disc may be incompatible.
No picture The TV selector is not set correctly.
No sound • Make sure that the input selector of the
amplifier is set correctly.
• The player is in the Special playback
mode.
• Select the correct Audio Output position
on the AV amplifier.
Picture is distorted
during CUE or REVIEW
The picture will be distorted occasionally.
You cannot stop
playback, or search,
slow-motion play,
repeat play, or
program play
Some discs may not allow some functions.
No on-screen display Select Display On.
No surround sound The setup does not match your stereo
system.
The unit or remote
operation keys are not
working
Turn off the player and unplug the AC power
cord for several minutes, then plug it in
again.
Problem Solution
Playback does not
start when the title is
selected
Check the Parental setup.
The audio soundtrack
or subtitle language is
not changed when
you play back a DVD
Multiple languages are not recorded on the
DVD disc.
No subtitles • Some discs have no subtitles.
• Subtitles are cleared. Press SUBTITLE.
The angle cannot be
changed
Multiple angles are not recorded on the DVD.
“X” appears on the
screen.
The function chosen is prohibited by the
player or the disc.
Remote control
The remote control
does not function.
• Aim at the remote control at the remote
sensor.
• Operate within about 15 feet (5 m) of the
TV, or reduce the light in the room.
• Clear the path of the beam.
• The batteries are weak. Replace the
batteries.
• Make sure that the batteries are inserted
correctly.
General
Power supply
120V AC 60 Hz
Power consumption
Operation: 65 W
Standby: 0.8 W
Weight
12.8 lbs. (5.8 kg)
Dimensions
(W×H×D)
21.25 × 17.5 × 8.25 inches
(53.7 × 43.95 × 20.7 cm)
Operating
temperature
41°F - 104°F (5°C - 40°C)
Operating humidity
Less than 80%
Televisi on
Type
21.6 inches (548.0 mm) diagonal
Display method
Transmission TFT color LCD panel
Number of pixels
1680 (H) × 1050 (V)
Viewing angle
Left/Right 85/85 degrees
Up/Down 80/80 degrees
Tuner type
NTSC standard
ATSC standard (8VSB), QAM
Receiving channels
VHF 2-13
UHF 14-69
CATV 14-36 (A)-(W)
37-59 (AA)-(WW)
60-85 (AAA)-(ZZZ)
86-94 (86)-(94)
95-99 (A-5)-(A-1)
100-125 (100)-(125)
01 (5A)
Problem Solution
