GFK-2059 2-1
Configuration and Installation
This chapter contains configuration and installation instructions for the Digital-to-Analog
Converter Board, and is divided into the following sections:
Physical Installation
Configuration
Before Apply Power: Checklist
Board Address Selection Switches
Address Modifier Response Selection
Digital Code Selection
Program Controlled and External Start Convert Mode
Connector Descriptions
Analog Output Accuracy
DAC Zero Offset and Gain Calibration
Caution
Some of the components assembled on GE Fanuc’s products may be
sensitive to electrostatic discharge and damage may occur on boards that are
subjected to a high energy electrostatic field. Unused boards should be
stored in the same protective boxes in which they were shipped. When the
board is to be placed on a bench for configuring, etc., it is suggested that
conductive material be inserted under the board to provide a conductive
shunt.
Upon receipt, any precautions found in the shipping container should be observed. All items should
be carefully unpacked and thoroughly inspected for damage that might have occurred during
shipment. The board(s) should be checked for broken components, damaged circuit board(s), heat
damage, and other visible contamination. All claims arising from shipping damage should be filed
with the carrier and a complete report sent to GE Fanuc together with a request for advice about the
disposition of the damaged item(s).
