2-2 IC697VAL348 8-Channel, 16-bit Digital-to-Analog Converter Board User’s Manual GFK-2059
– December 2001
2
Physical Installation
Caution
Do not install or remove boards while power is applied.
To install the board, de-energize the equipment and insert the board into an appropriate slot of the
chassis while ensuring that the board is properly aligned and oriented in the supporting card guides.
Slide the board smoothly forward against the mating connector until firmly seated. Review
“Configuration” on page 2-3 and “Before Applying Power: Checklist” on page 2-4 before operating
the board.
