Krell Industries DVD Standard DVD Player User Manual



Choose and Connect the Video Outputs
Choose the output that matches your video monitor. The DVD
Standard supports both progressive scan video (noninterlaced) and
standard video (interlaced) outputs. Options for each are explained
on the following pages.
The component YPbPr outputs will provide the best quality picture
when connected to a television capable of accepting a 480p sig-
nal. This includes most plasma, D-ILA, DLP, and HDTV ready
televisions.
6 Krell DVD Standard
To connect the DVD Standard to your video monitor, you need to:
connect to AC power, choose your video format, choose and then
connect video outputs, and configure the DVD Standard to match
your television format. These steps are explained below.
Match the video format (NTSC/PAL) of the monitor and the video sig-
nal of the DVD Standard to avoid a distorted picture.
Connect to AC Power
Plug the AC cord into the wall outlet. The red stand-by LED (3) illumi-
nates.
Choose the Video Format
Set the NTSC/PAL switch (25) on the back panel to the format that
matches your video monitor. See your monitor’s owner’s manual for
information.
Getting Started
The NTSC/PAL switch is active only when the DVD Standard is in the
stand-by mode. Changing the switch position while the component is
in the operational mode will not change the video format.
IMPORTANT
IMPORTANT
READ THIS FIRST
Step 1
Step 2
Step 3
