Remote Control Description
See Figure 3 on page 19
20 Krell DVD Standard
The DVD Standard remote control uses one CR2025 lithium battery,
which is included with the shipment.
To open the battery compartment on the back of the remote control:
1. Place the remote face down on the table.
2. Use your thumbnail or a small jeweler’s or eyeglass screwdriver
to move the small tab toward the center of the remote, while
using your index fingernail or screwdriver to pull down gently on
the slot to the right of the tab. The battery compartment will slide
out.
3. Place the battery, positive (+) side up, in the battery tray.
4. Slide battery compartment back into the remote until you hear a
click.
The remote control is ready for operation.
Do not use a knife or other sharp object to open the battery compartment;
they will scratch the remote control finish.
Replace batteries when remote control function becomes intermittent.
Remove batteries if the remote control is not used for a long time. Battery
leakage can damage the remote control.
The DVD Standard remote control provides power, standard and
advanced disc functions, and setup and programming functions. A
description of the remote control keys for the DVD Standard follows.
38 Power Key
Use this key to switch the DVD Standard from the stand-by to the
operational mode. The blue power LED on the front panel illuminates.
39 Audio Key
Use this key to cycle between the languages available on the disc
soundtrack. Options appear in the upper left corner of the video dis-
play. The last item scrolled to is automatically selected.
Notes
Battery Installation
and Removal
Remote Control
Functions
POWER
ADVANCED DISC
FUNCTIONS
