CHAPTER 4 PROCEDURES BEFORE OPERATION
4
CHAPTER 4 PROCEDURES BEFORE OPERATION
This chapter lists the procedures before operation.
( Page 31, Section 5.1)
( Page 35, Section 6.2, Page 47, Section 6.3, Page 49,
Section 6.4)
( Page 53, Section 7.1)
( Page 54, Section 7.2)
( Page 55, Section 7.3)
( Page 56, Section 7.4, Page 57, Section 7.5)
( Page 88, CHAPTER 10)
Start
Module installation
Connect the high-speed counter module.
Wiring
Connect an external device to the high-speed counter module.
Add the model name of the high-speed counter module.
Adding the model name of the intelligent function module
Switch setting
Set a pulse input mode, counting speed, and counter type.
Set an output mode if a CPU stop error occurs and CPU module
operation mode if a high-speed counter module error is detected.
Intelligent function module detailed setting
NO
YES
Use intelligent function module parameters?
Configure the parameter and auto refresh settings.
Parameter setting and auto refresh setting
Programming and debugging
Create and check a program.
