Panasonic DMR-E51 DVD Recorder User Manual



7
Batteries
Insert so the poles (- and +) match those in the remote control.
Do not use rechargeable type batteries.
Do not;
mix old and new batteries
use different types at the same time
heat or expose to flame
take apart or short circuit
attempt to recharge alkaline or manganese batteries
use batteries if the covering has been peeled off
Mishandling of batteries can cause electrolyte leakage which can
damage items the fluid contacts and may cause a fire.
If electrolyte leaks from the batteries, consult your dealer.
Wash thoroughly with water if electrolyte comes in contact with any
part of your body.
Remove if the remote control is not going to be used for a long
period of time. Store in a cool, dark place.
Replace if the unit does not respond to the remote control even
when held close to the front panel.
Use
Aim at the sensor, avoiding obstacles, at a maximum range of 7 m
directly in front of the unit.
Keep the transmission window and the unit’s sensor free from
dust.
Operation can be affected by strong light sources, such as direct
sunlight, and the glass doors on cabinets.
(1) Remote control signal sensor
(2) 7 m directly in front of the unit.
(3) Switch [DVD, TV] (15) to “DVD”.
Do not;
put heavy objects on the remote control
take the remote control apart
spill liquids onto the remote control
Television operation
You can control televisions by changing the remote control code.
Preparation
Turn on the television.
Switch [DVD, TV] (15) to “TV”.
1 Refer to the chart below for the code for your
television.
2 Press and hold [TV, Í] (14) and enter the two-digit
code with the numeric buttons (4).
For example: 01, press [0] )[1].
After entering the code, test the remote control by turning on
the television and changing channels.
Notes
If there is more than one code, repeat the procedure until you find
the code that allows correct operation.
Repeat this procedure after you change the batteries.
If your television brand is not listed or if the code listed for your
television does not allow control of your television, this remote is
not compatible with your television.
List of TVs Compatible with the unit’s Remote Control
Brand: Code
Panasonic/National 01, 02, 03, 04
SONY 05
TOSHIBA 06
JVC 07
HITACHI 08
MITSUBISHI 09, 10
SHARP 11
PHILIPS, SAMSUNG 12
NEC 13
SANYO 14
GOLDSTAR/LG 15, 16
SAMSUNG 17, 18
SANYO 19
Operation: Button
On and off: [TV, Í] (14)
Video input mode: [AV] (3)
Channels: [W, X, CH] (18)
Volume: [i, j, VOLUME] (19)
Numeric: [0-9, -/--] (4)
R6, AA, UM-3
30
30
(1)
(2)
(3)
TV
DVD
20
20
The remote control
