DVD-R4000
Setting up
U Power button. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7, 14
V Disc tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
W Channel buttons for recorder (CHANNEL). . . . . . . . . . . . . .14
X L2 input terminals (L2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Y Display
Z Time slip indicator (TIME SLIP). . . . . . . . . . . . . . . . . . . . . . .22
[ Skip/Slow/Search buttons (82 /6,5/9) . . . . . . .18, 19
A Timer recording display
On: When timer recording is on standby (➜page 24)
Flashes: When the unit couldn’t go to timer recording standby
B Disc type
C The display mode of the main display section
GRP: Group number
TITLE: Title number
PL: Play list number
CHAP: Chapter number
PG: Program number
TRACK: Track number
D Recording mode (➜page 15)
E DVD indicator
Flashes: When you press [Í, DVD POWER] to turn the unit
off until it actually turns off
F Channel
G Main display section
Recording and play counter, and other miscellaneous messages
Main unit
V
Y
X
W
[
Z
U
The unit’s display
A
B
C
E
D
F
G
Center circle (e.g., DVD-RAM)
Rotating (REC) :Recording
Stopped (REC) :Recording paused
Rotating (REC, PLAY) :
Chasing play or simultaneous
recording and play is in progress
Rotating (PLAY) : Playing
Stopped (PLAY) : Play paused
“PLAY” flashes :
The resume function (
➜
page 16,
To stop play) is working
