Samsung UN19D4003 Flat Panel Television User Manual



12
English
Basic Features
¦ Changing the Picture Options
Advanced Settings
O
MENU
m
Picture Advanced Settings
ENTER
E
(available in Standard / Movie mode)
Compared to previous models, new Samsung TVs have
more precise pictures.
Black Tone : Off
Dynamic Contrast : Medium
Gamma : 0
Color Space : Native
White Balance :
Flesh Tone : 0
Edge Enhancement : On
Advanced Settings
T V
U Move E Enter R Return
Sound
Channel
Setup
Input
Black Tone (Off / Dark / Darker / Darkest): Select the
black level to adjust the screen depth.
Dynamic Contrast (Off / Low / Medium / High):
Adjust the screen contrast.
Gamma: Adjust the primary color intensity.
Color Space (Auto / Native): Adjust the range of colors
available to create the image.
White Balance: Adjust the color temperature for a more
natural picture.
R-Offset / G-Offset / B-Offset: Adjust each color's
(red, green, blue) darkness.
R-Gain / G-Gain / B-Gain : Adjust each color's (red,
green, blue) brightness.
Reset: Resets the White Balance to it's default
settings.
Flesh Tone: Emphasize pink "flesh tone".
Edge Enhancement (Off / On): Emphasize object
boundaries.
Picture Options
O
MENU
m
Picture Picture Options
ENTER
E
Color Tone : Normal
Size : 16:9
Digital Noise Filter : Off
HDMI Black Level : Normal
Film Mode : Off
Picture Options
T V
U Move E Enter R Return
Sound
Channel
Setup
Input
Color Tone (Cool / Normal / Warm1 / Warm2)
Warm1 or Warm2 is only activated when the picture
mode is Movie.
Settings can be adjusted and stored for each external
device connected to an input on the TV.
Size: Your cable box/satellite receiver
may have its own set of screen sizes as
well. However, we highly recommend
you use 16:9 mode most of the time.
16:9: Sets the picture to 16:9 wide
mode.
Wide Zoom: Magnifies the picture size more than 4:3.
Adjusts the position( ) by using , buttons.
Zoom: Magnifies the 16:9 wide
Adjusts the position( ) or size( ) by using ,
button.
4:3: Sets the picture to basic (4:3) mode.
Do not watch in 4:3 format for a long time. Traces
of borders displayed on the left, right and center
of the screen may cause image retention (screen
burn) which are not covered by the warranty.
Screen Fit: Displays the full image without any cut-off
when HDMI (720p / 1080i / 1080p) or Component
(1080i / 1080p) signals are input.
NOTE
x
Depending on the input source, the picture size
options may vary.
x
The available items may differ depending on the
selected mode.
P
POWER
ADGUIDE
MEDIA.P
SUBT.
DUAL
P.MODES.MODE
P.SIZE
SRS
