Samsung UN19D4003 Flat Panel Television User Manual



25
English
05 Other Information
Specifications
Environmental Considerations
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
50°F to 104°F (10°C to 40°C)
10% to 80%, non-condensing
-4°F to 113°F (-20°C to 45°C )
5% to 95%, non-condensing
Model Name UN19D4003 UN32D4003 LN32D403
Display Resolution 1360X768
Screen Size
(Diagonal)
19 inches
(18.5" measured diagonally)
32 inches
(31.5" measured diagonally)
32 inches
(31.5" measured diagonally)
Sound Output 3W X 2 5W X 2
Dimensions (WxDxH)
Body
With stand
17.6 X 1.5 X 10.9 inches
(447.2 X 39.9 X 277.8 (mm))
17.6 X 4.8 X 12.3 inches
(447.2 X 124.0 X 312.4 (mm))
29.7 X 1.8 X 17.8 inches
(756.4 X 47.8 X 454.0 (mm))
29.7 X 7.1 X 19.6 inches
(756.4 X 182.4 X 498.1 (mm))
30.8 X 3.9 X 19.8 inches
(784.4 X 98.1 X 502.9 (mm))
30.8 X 7.1 X 21.4 inches
(784.4 X 182.4 X 545.3 (mm))
Weight
Without Stand
With Stand
6.1 Ibs (2.8 kg)
6.3 Ibs (2.9 kg)
13.8 Ibs (6.3 kg)
15.8 Ibs (7.2 kg)
16.7 Ibs (7.6 kg)
18.9 Ibs (8.6 kg)
Model Name UN22D5003 UN40D5003 LN40D503
Display Resolution 1920X1080
Screen Size
(Diagonal)
22 inches
(21.5" measured diagonally)
40 inches
(40.0" measured diagonally)
40 inches
(40.0" measured diagonally)
Sound Output 3W X 2 10W X 2
Dimensions (WxDxH)
Body
With stand
20.3 X 1.5 X 12.4 inches
(515.8 X 39.9 X 315.6 (mm))
20.3 X 4.8 X 13.7 inches
(515.8 X 124.0 X 350.0 (mm))
37.1 X 2.0 X 22.1 inches
(943.8 X 51.0 X 561.4 (mm))
37.1 X 8.6 X 23.7 inches
(943.8 X 219.4 X 603.5 (mm))
38.1 X 3.8 X 23.0 inches
(970.0 X 98.1 X 586.6 (mm))
38.1 X 8.1 X 24.7 inches
(970.0 X 206.9 X 629.1 (mm))
Weight
Without Stand
With Stand
7.4 Ibs (3.4 kg)
7.7 Ibs (3.5 kg)
21.1 Ibs (9.6 kg)
24.2 Ibs (11.0 kg)
25.5 Ibs (11.6 kg)
29.3 Ibs (13.3 kg)
Design and specifications are subject to change without prior notice.
For information about power supply, and more about power consumption, refer to the label attached to the product.
¦ License
TruSurround HD, SRS and
symbol are trademarks of SRS Labs, Inc.
TruSurround HD technology is incorporated under license from SRS Labs, Inc.
Open Source License Notice
In the case of using open source software, Open Source Licenses are available on the product menu.
Open source used in this product can be found on the following webpage. ( http://opensource.samsung.com )
Open source License Notice is written only English.
