WATCHING IMAGES2
English 17
(6) Image mode
LIVE: Live mode
PLAY: Play mode
(7) Time
Live mode: Displays the current time
Play mode: Displays the recording time
(8) NORMAL RECORDING MODE
This item displays the current condition for normal
recording.
z STOP
z RECORDING
z TIMER STANDBY
z TIMER RECORDING
z AREA FULL (in normal recording area)
(9) ALARM RECORDING MODE
This item displays the current condition for alarm
recording.
z STOP
z PRE ALARM RECORDING
z ALARM RECORDING
z AREA FULL (in alarm recording area)
(10)Connection user
In situations where a number of different users are
connected, this item displays the connection condition for
the various user levels.
Typical display: ID1: 3 ID2: 1 ID3: 0
The user ID for the current user is displayed in red.
(11)PLAYBACK AREA (in the play mode screen only)
This item displays the recording area for the current
playback image.
z NORMAL
z ALARM
z PREALRAM
z ARCHIVE
(12)SPEED (in the play mode screen only)
This item displays the playback speed and direction.
z If video with audio is to be downloaded to a PC, DVR
Viewer must be installed before the necessary settings
can be made. (JP. 2)
1 Live images will be displayed when
connected with user level ID2 or ID3.
2 Set “SAVE TO PC” to “ON” and then
click [SET].
The save setting items are displayed.
Screen display items
Display Playback direction Playback speed
PLAY Forward Normal
STILL Still Still
R.PLAY Reverse Normal
CUE Forward Fast-forward playback
REVIEW Reverse Fast-rewind playback
SLOW Forward Slow playback
R.SLOW Reverse Slow reverse playback
Settings for downloading live images
to a PC
LIVE
NORMAL RECORDING MODE
01-01-04 00: 40: 32
ALARM RECORDING MODE
READ INTERVAL :
SAVE TO PC :
SIZE :
QUALITY :
AUDIO :
OFF
1
2
1
01
OFF
SET
STOP
STOP
CAMERA CONTROL
DURATION :
DESTINATION
FOLDER :
MIN
HR :
BROWSE
LIVE
NORMAL RECORDING MODE
01-01-04 00: 00: 00
ALARM RECORDING MODE
READ INTERVAL :
SAVE TO PC :
SIZE :
QUALITY :
AUDIO :
OFF
1
2
1
01
ON
SET
STOP
STOP
S
TAR T
01
C:\
00
